ABB 3HAC12929-1/04 Teaching Pendant

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 3HAC12929-1/04 is a teaching pendant for ABB industrial robots, enabling operators to perform manual control, program teaching, and debugging. Equipped with high-precision control buttons, an emergency stop switch, and a user-friendly display, it allows intuitive and safe robot operation, making it essential for ABB automation applications.

This model is compatible with multiple ABB robot series and supports manual teaching, waypoint programming, path editing, and robot parameter configuration.

2. Main Technical Specifications

• Model: 3HAC12929-1/04

• Type: Teaching Pendant

• Compatible Robot Series: ABB IRB, YuMi, IRB 1200/1600/2600, etc. (verify controller compatibility)

• Display: Color LCD screen (shows robot status, coordinates, program info)

• Control Buttons:

  • Multi-axis JOG control buttons

  • Speed adjustment knob

  • Emergency stop button

  • Function and navigation keys

• Communication Interface: RJ45 / proprietary robot bus interface

• Supply Voltage: 24 V DC (from robot controller)

• Response Time: <10 ms

• Safety Standard: Emergency stop meets ISO 10218-1 / ISO 13849

• Operating Temperature: 0°C to +50°C

• Humidity: 10%–90% RH (non-condensing)

• Protection Class: IP65 (handheld portion dust- and water-resistant)

• Cable Length: 5 m / 10 m (customizable)

• Weight: Approx. 1.2 kg

3. Advantages and Features

1. Safety and Reliability

• Built-in emergency stop allows instant halting of robot motion.

• Compliant with international robot safety standards ISO 10218 and IEC 61508.

2. High-Precision Control

• Multi-axis JOG buttons and speed knob for precise manual operation.

• Supports fine incremental movements for path teaching and debugging.

3. User-Friendly Interface

• Color LCD displays robot status, coordinates, and operation mode.

• Well-organized function and navigation keys for intuitive operation.

4. Modular and Compatible

• Compatible with multiple ABB controllers and robot series.

• Standard interface connection without additional converters.

5. Durable Industrial Design

• IP65-rated, suitable for dusty or humid industrial environments.

• Robust handle and cable for long-term reliability.

4. Typical Application Areas

• ABB industrial robot teaching and debugging

• Automated production line waypoint programming

• Robot welding, material handling, assembly teaching

• Industrial training and laboratory teaching

• Factory automation system maintenance and setup

5. Precautions

1. Ensure the pendant is compatible with the robot controller.

2. Avoid pulling or stressing the cable; ensure connections are secure.

3. Press the emergency stop button immediately in case of abnormal robot motion.

4. Do not operate in high humidity, strong electromagnetic interference, or flammable/explosive environments.

5. Regularly inspect buttons, knobs, and display for proper function.

6. Store the pendant in a dry, pressure-free, and moderate-temperature environment.

7. Select cable length according to site layout to prevent tripping or damage.
