ABB 5SHX0660F0001 IGBT (Insulated Gate Bipolar Transistor) Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 5SHX0660F0001 is a high-performance Insulated Gate Bipolar Transistor (IGBT) Module, widely used in industrial drives, traction inverters, power conversion systems, and high-speed switching power supplies. Combining the high input impedance of MOSFETs with the low saturation voltage of BJTs, it provides high efficiency, reliability, and fast switching capability, ensuring stable operation under high voltage and high current conditions.

The module features a modular package, facilitating heat dissipation and integration in industrial systems. It is suitable for applications requiring high power density and high switching frequency.

2. Main Technical Specifications

• Model: 5SHX0660F0001

• Type: IGBT Module

• Configuration: Single-phase bridge or half-bridge (depending on design)

• Rated Collector Current (Ic): 660 A

• Rated Collector-Emitter Voltage (Vce): 1200 V

• Gate-Emitter Voltage (Vge): ±20 V

• Saturation Voltage (Vce(sat)): ~2.3 V

• Switching Frequency Range: up to 5 kHz (depends on cooling and application)

• Power Dissipation: ~600–800 W (depending on cooling)

• Insulation Voltage: 2.5 kV AC (collector to base)

• Operating Temperature: -40°C to +150°C

• Storage Temperature: -40°C to +125°C

• Package Type: Modular with heatsink base

• Electrical Connection: Bolt or clamp type

• Weight: ~1.2 kg

3. Advantages and Features

1. High Performance and Efficiency

• Low saturation voltage reduces power loss and increases overall system efficiency.

• Fast switching supports high-frequency operation and precise control.

2. High Reliability and Durability

• Industrial-grade packaging withstands high temperature and current.

• Internal protection structures reduce risk of short-circuit, overvoltage, and thermal runaway.

3. Easy Heat Dissipation and Integration

• Modular design allows easy mounting on heatsinks for efficient thermal management.

• Compatible with various industrial inverters and power electronics systems.

4. Broad Application Compatibility

• Suitable for AC drives, DC traction systems, inverter UPS, and other industrial power applications.

5. Precision Control and Safety

• Fast switching characteristics support PWM control strategies.

• Compliant with industrial safety and protection standards.

4. Typical Application Areas

• Industrial variable frequency drives (VFD)

• Traction drive systems

• Inverters and uninterruptible power supplies (UPS)

• Renewable energy systems (wind, PV inverters)

• Power electronics and high-power switching

• High-speed industrial automation drives

5. Precautions

1. Ensure module voltage and current ratings match the application.

2. Mount securely on heatsinks with appropriate thermal interface materials.

3. Ensure electrical connections are secure to avoid overheating or damage.

4. Operating beyond temperature limits reduces module lifetime; implement proper thermal monitoring.

5. Avoid gate overvoltage or reverse voltage; ensure proper gate driver design.

6. Avoid usage in humid, corrosive, or vibration-prone environments.

7. Include overcurrent, overvoltage, and short-circuit protection in system design.
