ABB GVC703AE01 Thyristor Control Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB GVC703AE01 is an industrial Thyristor Control Module used to regulate power output for AC loads. By controlling the thyristor trigger signal, it provides precise power control for high-power electric heaters, motor drives, and industrial furnaces. The module features fast response, stable triggering, and is a key component in ABB industrial automation and power electronics systems.

The module supports both digital and analog input signals, offering flexible configuration for a wide range of industrial power control applications.

2. Main Technical Specifications

• Model: GVC703AE01

• Type: Thyristor Control Module

• Control Method: Phase Angle Control / Full-Wave Triggering

• Applicable Loads: Resistive or inductive loads

• Trigger Current: Max 50 mA

• Trigger Voltage: 15–24 V DC

• Operating Voltage: 3×380–480 V AC (system dependent)

• Rated Output Current: 60–100 A (depending on load configuration)

• Control Interfaces:

  • Analog input 0–10 V or 4–20 mA

  • Optional digital input

• Switching Frequency: 50/60 Hz

• Isolation Voltage: 2.5 kV AC (control to power)

• Operating Temperature: -20°C to +60°C

• Storage Temperature: -40°C to +85°C

• Protection Class: IP20

• Mounting: DIN rail or cabinet mount

• Dimensions & Weight: Modular design, approx. 1–1.5 kg

3. Advantages and Features

1. Precise Power Control

• Supports phase angle and full-wave triggering for continuous load power adjustment.

• High-speed triggering ensures stable and responsive output.

2. High Reliability

• Industrial-grade components withstand high temperature and continuous operation.

• Internal protection minimizes risk of short-circuit or overload.

3. Easy Integration

• Modular design fits DIN rails or cabinets, allowing system expansion.

• Compatible with analog and digital controllers.

4. Safety and Protection

• 2.5 kV AC isolation between control and power circuits improves system safety.

• Built-in overcurrent and overvoltage protection.

5. Industrial Application Compatibility

• Suitable for ABB SCR power supplies, industrial furnace control, and heater regulation systems.

4. Typical Application Areas

• Industrial electric furnaces and melting furnaces

• Electric heater power regulation

• Industrial power conversion and regulation systems

• Drying equipment and plastic processing machinery

• Automated production line power control

• Power electronics drive systems

5. Precautions

1. Ensure input voltage and rated current match the load before installation.

2. Proper grounding is required; avoid humid, dusty, or corrosive environments.

3. Secure all electrical connections to prevent trigger failure or overheating.

4. Control signal voltage and current must meet module specifications.

5. Ensure adequate cooling during operation to prevent overheating.

6. Regularly inspect terminals, heatsinks, and trigger circuits.

7. In case of alarm or trigger failure, power off immediately and investigate.
