ABB ACS-CP-D Control Panel

Product Description

Key Specs

• Compatible Inverters: ABB ACS880 (all frames), ACS580 (frame R3-R8), ACS608 series inverters (via 6-pin RJ45 or optional USB-C adapter).
• Display: 4-line backlit LCD (20 characters/line), high contrast (adjustable 5 levels) for outdoor or bright industrial environments.
• Operation Interface: 8 programmable function keys + navigation wheel (supports fast parameter scrolling) + dedicated Reset/Emergency Stop keys.
• Data Storage: Built-in 2MB memory (stores up to 10 parameter sets, 50 fault logs); supports USB-C for data export/import.
• Power Supply: 24V DC from inverter auxiliary port (≤1.2W power consumption); optional 5V USB-C power (for offline parameter editing).
• Env: -10°C~+55°C, 5%-95% RH (non-condensing); IP54 (dust-proof, water-splash resistant—suitable for on-site outdoor use).
• Mounting: 3 modes—panel-mounted (cutout: 92×55mm), handheld (with 3m/5m extension cable), rack-mounted (via optional bracket).

Core Functions (Upgraded vs. ACS-CP-C)

1. Enhanced Control Capabilities:
   • Supports multi-step speed control (up to 16 preset speeds) and torque limit adjustment (for tension control in winding machines).
   • Enables local/remote control switching (seamless handover between panel and PLC control).
2. Advanced Monitoring:
   • Real-time display of 4 parameters simultaneously (e.g., current, voltage, frequency, motor temperature) vs. 2 in ACS-CP-C.
   • Historical data logging (1-minute interval, 72-hour storage) for trend analysis (e.g., energy consumption tracking).
3. Intelligent Parameter Management:
   • USB-C port for fast parameter backup/restore (saves to USB drive) and firmware updates (no need to disconnect from the inverter).
   • Parameter search via keyword (e.g., "acceleration time")—reduces commissioning time vs. manual scrolling.
4. Fault Diagnosis:
   • Records 50 fault events (with timestamp, current/frequency at fault) vs. 10 in ACS-CP-C; supports fault code translation to local language.
   • Built-in diagnostic tools (e.g., motor insulation resistance test reminder) for predictive maintenance.

Core Advantages

1. Higher Environmental Adaptability: IP54 rating allows direct use in harsh on-site environments (e.g., outdoor water pump stations) without additional enclosures.
2. Efficient Data Management: USB-C and large memory simplify batch commissioning (e.g., 20 ACS880 inverters in a factory) and fault traceability.
3. Customizable Operation: 8 programmable keys can be set to frequently used functions (e.g., "Tension Increase" for printing machines) to optimize operator efficiency.
4. Multi-Language Support: 15 languages (English, Chinese, German, etc.)—suitable for global industrial sites with multi-national teams.

Applications

1. Complex Inverter Commissioning: Used for ACS880 inverters in steel mill rolling lines—sets multi-step speed curves and backs up parameters via USB.
2. Outdoor Industrial Sites: Controls ACS580 inverters in solar water pump systems (IP54 resists rain/sand) and monitors real-time flow/pressure.
3. Predictive Maintenance: Tracks fault history and parameter trends for ACS608 inverters in marine propulsion systems, reducing unplanned downtime.

Precautions

1. Adapter Requirement: For ACS580 frame R1-R2, use ABB’s dedicated RJ45-USB adapter (part no. 3ABD00019449) to ensure compatibility.
2. USB Operation: Only use ABB-approved USB drives (FAT32 format) for data export—unapproved drives may cause data corruption.
3. Mounting Torque: For panel-mounted installation, tighten screws to 1.0-1.2N·m (over-tightening damages the panel housing).
4. Waterproof Protection: Though IP54-rated, avoid direct high-pressure water jetting (limit to occasional splashes).
5. Firmware Compatibility: Ensure panel firmware version matches inverter firmware (v2.1+ recommended for ACS880 v6.0+)
