ABB ACS-CP-C Basic Control Panel

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB ACS-CP-C Basic Control Panel

Product Description

Key Specs

• Compatible Inverters: ABB ACS880, ACS580, ACS550, ACS355 series inverters (via dedicated 6-pin RJ45 connector).
• Display: 2-line LCD (16 characters/line), backlit (adjustable brightness) for low-light environments.
• Operation Buttons: 6 function keys (Start/Stop, Forward/Reverse, Speed Up/Down, Reset, Enter, Escape) + navigation dial.
• Power Supply: Takes 24V DC from inverter’s auxiliary port (no external power required); power consumption ≤1W.
• Env: -10°C~+50°C, 5%-95% RH (non-condensing); IP40 (dust-proof, suitable for cabinet-mounted or on-site use).
• Mounting: 2 installation modes—panel-mounted (cutout size: 78×45mm) or handheld (with optional cable extension).

Core Functions

1. Basic Inverter Control:
   • Start/stop inverter operation, switch forward/reverse rotation.
   • Adjust output frequency (0-50/60Hz) via Speed Up/Down keys or navigation dial.
2. Status Monitoring:
   • Real-time display of key parameters: output current, voltage, frequency, motor speed, power.
   • Visual fault/alarm indication (e.g., overcurrent, overvoltage) with error code display.
3. Parameter Configuration:
   • Access and modify basic inverter parameters (e.g., acceleration/deceleration time, motor rated current).
   • Save/load parameter sets for quick commissioning of multiple identical inverters.
4. Fault Handling:
   • View fault history (last 10 faults) for troubleshooting.
   • One-key reset of non-critical faults (e.g., minor overheating after cooling).

Core Advantages

1. Plug-and-Play Compatibility: Directly connects to inverter’s control port—no additional wiring, ready to use immediately.
2. Intuitive Operation: Simple key layout + backlit LCD; no professional training required for basic operations.
3. Dual-Mount Flexibility: Panel-mounted for fixed cabinet setups, handheld for on-site debugging (via 1m/3m extension cables).
4. Cost-Effective: Provides essential control/monitoring functions at a lower cost than advanced panels (e.g., ACS-CP-D), suitable for basic application needs.

Applications

1. On-Site Inverter Commissioning: Used by technicians to set basic parameters (motor specs, control modes) for ACS880 inverters in conveyor systems.
2. Daily Operation of Single Inverters: Operators use it to start/stop ACS580 inverters in water pump systems and monitor real-time flow-related frequency.
3. Fault Troubleshooting: Maintenance personnel check fault codes via the panel to quickly identify issues (e.g., overcurrent in ACS355 fan inverters).

Precautions

1. Compatibility Check: Confirm inverter model is ACS series (not compatible with DCS series DC drives); use original ABB 6-pin cable.
2. Mounting: For panel-mounted installation, ensure cutout size matches (78×45mm) to avoid panel damage; tighten mounting screws to 0.5-0.8N·m.
3. Environmental Protection: Avoid direct water splashing (IP40 not waterproof); clean the panel surface with a dry cloth (no corrosive cleaners).
4. Parameter Safety: Lock critical parameters (e.g., motor rated current) via inverter password after commissioning to prevent misoperation.
5. Cable Protection: For handheld use, avoid pulling the extension cable forcefully to prevent connector damage.

The structure and details of the product：
