ABB ACS/H-CP-EXT Panel Extension Cable Kit

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB ACS/H-CP-EXT Panel Extension Cable Kit

Product Description

Key Specs

• Compatible Panels: ABB ACS-CP-C (basic), ACS-CP-D (advanced), H-CP-A (H-series) control panels.
• Compatible Inverters: Matches ACS880, ACS580, ACS550, ACS355 series inverters (via inverter’s 6-pin control port).
• Cable Specifications:
  • Conductor: 6-core tinned copper (0.25mm²/strand, 7 strands total), low-resistance for stable signal transmission.
  • Insulation: PVC sheath (flame-retardant, UL94 V-0), oil-resistant and wear-resistant.
  • Length Options: Standard 3m/5m; optional 10m (part no. varies by length, e.g., ACS-CP-EXT-3M for 3m).
• Connectors:
  • Inverter end: 6-pin male RJ45 (matches inverter control port, gold-plated contacts for anti-oxidation).
  • Panel end: 6-pin female RJ45 (locks with panel connector, IP40 protection when mated).
• Env: -20°C~+60°C, 5%-95% RH (non-condensing); cable sheath resistant to industrial oils and coolants.

Core Functions

1. Distance Extension: Extends panel-inverter connection from default <1m to 3-10m, allowing panels to be mounted in operator-friendly locations (e.g., control room consoles vs. on-inverter mounting).
2. Signal Integrity: Tinned copper conductors + shielded design (optional for 10m versions) reduce EMI interference, ensuring no loss of control signals (e.g., start/stop commands) or monitoring data (e.g., current/fault codes).
3. Plug-and-Play Installation: Pre-terminated with matched RJ45 connectors—no wiring or crimping required; simply plug into inverter and panel ports to use.

Core Advantages

1. Flexible Mounting: Enables remote panel placement (e.g., outside high-temperature inverter cabinets) to protect operators and ensure clear visibility of the panel display.
2. Durable Design: Flame-retardant, oil-resistant sheath withstands harsh industrial environments (e.g., automotive workshops, chemical plants) without cable degradation.
3. Reliable Connection: Gold-plated connectors prevent contact oxidation (common in humid environments), ensuring long-term stable communication (≥5000 mating cycles).
4. Safety Compliance: Meets IEC 60227 (cable standard) and EN 61010 (safety standard for industrial control equipment), reducing electrical hazards.

Applications

1. Large Control Cabinets: Extends ACS-CP-D panels from ACS880 inverters in tall switchboards to lower panel doors (3m length) for easy operator access.
2. Outdoor Inverter Installations: Connects ACS-CP-C panels to ACS580 inverters in outdoor water pump stations (5m length) — panels mounted in waterproof enclosures, cables routed through conduit.
3. Factory Control Rooms: Uses 10m shielded versions to link ACS-CP-D panels (in control rooms) to ACS355 inverters on production lines, enabling centralized monitoring without on-site visits.

Precautions

1. Length Matching: Do not exceed 10m (max supported length); longer cables cause signal attenuation, leading to delayed control or data loss.
2. Cable Routing: Avoid routing alongside high-voltage cables (≥380V) or inverters’ output cables—maintain ≥10cm spacing to reduce EMI interference.
3. Connector Protection: When disconnected, use the included dust caps (supplied in the kit) to cover connectors and prevent dust/water ingress.
4. Mechanical Stress: Avoid bending the cable at sharp angles (minimum bend radius: 15mm) or pulling it forcefully—prevents conductor breakage.
5. Kit Completeness: Verify kit includes 1 extension cable + 2 dust caps + installation guide before use; missing parts may affect installation safety.
