ABB ACS-AP-S 3AUA0000064884 control panel

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• •

  • 1. Product Description

    The ABB ACS-AP-S 3AUA0000064884 is a standard control panel designed for ABB ACS series variable frequency drives.
    It is compatible with ACS180, ACS380, ACS480, ACS530, ACS560, and ACS580 drives, providing a user interface for commissioning, operation, parameter setting, and diagnostics.
    The ACS-AP-S panel features a multilingual LCD display and supports local or remote control switching, enhancing ease of use and maintainability.

    ---

    2. Technical Specifications

    Item	Specification
    Model	ACS-AP-S
    ABB Part Number	3AUA0000064884
    Compatible Drives	ACS180, ACS380, ACS480, ACS530, ACS560, ACS580
    Display	Multilingual LCD screen
    Interface	RJ45 communication port
    Power Supply	Powered via drive communication port
    Mounting	Wall-mounted or panel-mounted
    Dimensions (H × W × D)	130 mm × 74 mm × 26 mm
    Weight	Approx. 0.13 kg
    Functions	Parameter setting, start/stop control, monitoring & diagnostics, time setting, local/remote control switching

    ---

    3. Features & Advantages

    • User-Friendly Interface: Multilingual LCD display simplifies drive operation and commissioning.

    • Comprehensive Diagnostics: Real-time monitoring and fault indication for easy troubleshooting.

    • Wide Compatibility: Supports multiple ABB ACS series drives.

    • Flexible Operation: Switchable between local and remote control for various applications.

    • Compact & Lightweight Design: Wall or panel mounting saves space and allows easy system integration.

    ---

    4. Application Fields

    • Industrial automation production lines

    • Water treatment and pump systems

    • Fans and HVAC systems

    • Conveyors and packaging machinery

    • Pharmaceutical, food & beverage, and chemical industries

    • Other industrial applications requiring precise motor control and remote monitoring

    ---

    5. Precautions

    1. Disconnect power before installation to ensure safety.

    2. Confirm compatibility of the control panel with the drive model.

    3. Install in a dry, well-ventilated environment; avoid high temperature, humidity, and corrosive gases.

    4. Ensure proper wiring and grounding of signal and communication lines to avoid interference.

    5. Regularly inspect panel and drive status to ensure proper operation.

    6. Operators should be familiar with panel functions and drive operation procedures.

    7. Avoid prolonged operation beyond specified temperature limits.

  •
  •
  •

The structure and details of the product：
