  • ABB CMOD-01 (3AXD50000004420) Expansion Module

    1. Product Description

    The ABB CMOD-01 (3AXD50000004420) is an I/O expansion module designed for ABB ACS580 and ACH580 variable frequency drives.
    It provides additional digital I/O functionality, enhancing the flexibility and control capabilities of the drives in industrial automation applications.
    The module allows integration with external control systems, PLCs, and other automation equipment, enabling expanded process control and monitoring capabilities.

    ---

    2. Technical Specifications

    Item	Specification
    Model	CMOD-01
    ABB Part Number	3AXD50000004420
    Digital Outputs	1 x Transistor Output (DO), 2 x Relay Outputs (RO)
    Power Supply	24 V DC/AC (external)
    Dimensions (L × W × H)	Approx. 132 mm × 114 mm × 40 mm
    Weight	Approx. 0.1 kg
    Mounting Type	External installation

    ---

    3. Application Fields

    The CMOD-01 module is suitable for applications that require additional digital I/O capabilities, such as:

    • Industrial automation: Integrating the drive with PLCs and other control systems.

    • Process control: Monitoring and controlling machinery and equipment.

    • Building management systems: Enhancing HVAC and other building system controls.

    • Diagnostics and fault finding: Maintaining operator keypad and control electronics operation even when the main drive supply is disconnected.

    ---

    4. Features & Advantages

    • Digital I/O Expansion: Adds 1 transistor output and 2 relay outputs, enabling extended control options.

    • External Power Supply: Supports 24 V DC/AC, allowing operation of control electronics independently of the main drive supply.

    • Compact Design: Can be installed externally, saving space within the drive unit and allowing flexible integration.

    • Easy Integration: Designed to seamlessly work with ACS580 and ACH580 drives for expanded functionality.

    ---

    5. Precautions

    • Ensure proper external power supply is connected before operation.

    • Install in a dry, ventilated environment to prevent damage from moisture or dust.

    • Avoid exposure to corrosive gases or extreme temperatures.

    • Follow ABB guidelines for mounting and wiring to ensure safe and reliable operation.

    • Regularly inspect the module and connections to maintain proper functionality.

  •
  •
  •
