• • ABB CDPI-01 (3AXD50000004419) Panel Bus Adapter

    1. Product Description

    The ABB CDPI-01 (3AXD50000004419) is a Panel Bus Adapter designed to facilitate communication between ABB ACS series variable frequency drives and remote control panels or PCs.
    It allows connection of control panels, such as the ACS-AP series, to the drive via an RJ-45 cable, enabling remote operation and monitoring.
    The module is suitable for integration into industrial automation systems requiring centralized control and enhanced accessibility.

    ---

    2. Technical Specifications

    Item	Specification
    Model	CDPI-01
    ABB Part Number	3AXD50000004419
    Type	Panel Bus Adapter
    Compatible Drives	ACS580, ACH580, ACQ580 series drives
    Interface	RJ-45 communication port
    Protection Rating	IP21 when installed
    Dimensions (H × W × L)	40 mm × 114 mm × 132 mm
    Weight	Approx. 0.15 kg
    Bus Configuration	Supports up to 32 nodes on the panel bus
    Communication Protocol	RS-485
    Mounting	Installed within drive cabinet

    ---

    3. Features & Advantages

    • Remote Connectivity: Enables remote operation and monitoring of drives, improving accessibility.

    • Scalability: Supports multiple drives on a single panel bus, simplifying system architecture.

    • Ease of Installation: Compact design allows straightforward integration into existing systems.

    • Enhanced Control: Facilitates centralized control of multiple drives, improving operational efficiency.

    ---

    4. Application Fields

    • Industrial automation: Centralized control of multiple drives in manufacturing lines.

    • HVAC systems: Efficient operation of heating, ventilation, and air conditioning systems.

    • Water treatment plants: Remote monitoring and control of pumps and motors.

    • Material handling: Coordinated control of conveyors and other handling equipment.

    • Building management systems: Integration with building automation for centralized monitoring and control.

    ---

    5. Precautions

    1. Ensure proper installation according to ABB guidelines to maintain IP21 protection.

    2. Verify compatibility of the adapter with the specific drive model before installation.

    3. Disconnect power before installation or maintenance to avoid electrical hazards.

    4. Install in a dry, well-ventilated environment to prevent overheating.

    5. Periodically inspect the adapter and connections to ensure reliable operation.

  •
  •
  •
