ABB 3HAB2213-1/2 DSQC 313 measuring board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB 3HAB2213-1/2 DSQC 313 Measuring Board Product Documentation

1. Product Description
The ABB 3HAB2213-1/2 DSQC 313 is a Measuring Board specifically designed for industrial automation and process control systems. As an important component of ABB robot control systems or automation equipment, this module is primarily used for precise measurement and monitoring of various process parameters, such as voltage, current, temperature, pressure, etc. It adopts high-precision sensors and advanced signal processing technology to achieve accurate data acquisition and real-time monitoring, making it suitable for various industrial scenarios requiring high-precision measurement and control1.

2. Detailed Parameters

3. Product Advantages and Features
3.1 High-Precision Measurement: Uses high-precision sensors and advanced signal processing technology to achieve accurate data acquisition and real-time monitoring, ensuring the accuracy and reliability of measurement results.
3.2 Multi-functional Input/Output: Supports multiple analog and digital input/output signals, adaptable to different measurement and control needs.
3.3 High Reliability Design: Uses industrial-grade design and high-quality components to ensure stable operation in harsh industrial environments, supporting a wide temperature range and high noise immunity.
3.4 Easy Integration and Maintenance: Modular design facilitates installation and configuration; status indicators enable real-time monitoring and troubleshooting, reducing maintenance costs.
3.5 Flexible Configuration: Supports multiple parameter settings and communication protocols, allowing flexible configuration based on actual application requirements.
3.6 Compact Design: Compact structure saves installation space, supports DIN rail mounting, and is easy to integrate into various control cabinets.

4. Application Fields
4.1 Industrial Automation: Used for production line automation control, machinery equipment control, etc., achieving precise parameter measurement and monitoring.
4.2 Process Control: Applied in process control systems in chemical, petroleum, and natural gas industries for precise measurement and control of temperature, pressure, flow, etc..
4.3 Power Systems: Used for equipment monitoring and control in power plants and substations, enabling precise measurement and monitoring of voltage, current, and other parameters.
4.4 Manufacturing: Automated production line control and quality monitoring in automotive manufacturing, food processing, pharmaceuticals, etc..
4.5 Infrastructure: Used for monitoring and control of public infrastructure such as building automation, traffic control systems, and water treatment facilities.

5. Precautions
5.1 Installation Environment: Ensure the operating environment temperature is between -20°C and +60°C, relative humidity ≤85% (non-condensing), and avoid corrosive gases and strong vibrations.
5.2 Power Requirements: Use a stable and reliable power supply with voltage within the specified range (e.g., 24V DC±10%); pay attention to power polarity to prevent reverse connection.
5.3 Wiring Specifications: Correctly connect signal lines; pay attention to shielding and grounding to reduce electromagnetic interference; use shielded cables for analog signal transmission and ensure proper grounding.
5.4 Parameter Settings: Reasonably set measurement parameters (e.g., range, filter time) according to actual application needs to avoid measurement errors or protection activation due to improper settings.
5.5 Maintenance and Diagnostics: Regularly check the module status; utilize self-diagnostic functions to monitor system status; update firmware promptly and replace aging components.
5.6 Safe Operation: When installing and maintaining, always follow safety procedures and power down if necessary to prevent electric shock or equipment damage.
