ABB RTAC-01 pulse encoder interface module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB RTAC-01 Pulse Encoder Interface Module Product Documentation

1. Product Description
The ABB RTAC-01 is a Pulse Encoder Interface Module specifically designed for ABB ACS800 series frequency converters1. The primary function of this module is to provide a connection interface for digital pulse encoders to obtain precise speed or position (angle) feedback information of the motor shaft. It adopts an industrial-grade design and advanced signal processing technology to achieve high-precision data acquisition and real-time monitoring, making it suitable for various industrial automation scenarios requiring precise speed control or position feedback.

2. Detailed Parameters

3. Product Advantages and Features
3.1 High-Precision Feedback: Provides accurate motor speed and position (angle) feedback information, ensuring the accuracy and reliability of the control system.
3.2 Wide Compatibility: Designed specifically for ABB ACS800 series frequency converters, compatible with various digital pulse encoders.
3.3 Flexible Configuration: Supports single-ended or differential input methods, with selectable signal voltage levels of 15V or 24V DC, adaptable to different application needs.
3.4 High-Performance Processing: Supports input frequencies up to 200 kHz, capable of handling encoder signals from high-speed rotating equipment.
3.5 Industrial-Grade Reliability: Uses industrial-grade design and high-quality components to ensure stable operation in harsh industrial environments.
3.6 Easy Installation and Integration: Modular design facilitates installation and configuration, providing standardized interfaces and connection methods.

4. Application Fields
4.1 Industrial Automation: Used for production line automation control, machinery equipment control, etc., achieving precise speed and position control.
4.2 Motor Control Systems: Serves as a feedback element in motor control systems for measuring motor speed and position, enabling precise control.
4.3 Master-Slave Control Applications: Particularly suitable for master-slave control scenarios with ABB ACS800 series frequency converters, supporting both rigid and flexible connection methods.
4.4 Precision Positioning Applications: In applications requiring precise positioning, the zero reference output channel (Z signal) provides accurate position reference.
4.5 High-Performance Drive Systems: Used in drive systems requiring high-precision speed control and position feedback, such as cranes, conveyors, etc..

5. Precautions
5.1 System Compatibility: This module is dedicated to ABB ACS800 series frequency converters; verify compatibility with the existing system before use.
5.2 Encoder Selection and Connection:
* Select an appropriate encoder (resolution, output type, etc.) based on application requirements.
* Correctly connect encoder signal lines (A, B, Z phases). When the drive unit is rotating forward, the output channel with the leading phase should be connected to input A of the RTAC, and the channel with the lagging phase to input B.
* When considering single-ended or differential connection, follow the manufacturer's recommended schemes.
5.3 Cable Length and Power Consumption: Be aware of the impact of encoder cable length on power consumption and choose cable length appropriately.
5.4 Environmental Conditions: Ensure operating environment parameters (temperature, humidity, vibration) are within the module's allowed range, although the module is designed for industrial environments.
5.5 Parameter Configuration: Configure frequency converter parameters according to the specific application, especially those related to the encoder interface (e.g., pulse count, signal type).
5.6 Maintenance and Diagnostics: Regularly check the operational status of the module and encoder; utilize the system's diagnostic functions for monitoring and maintenance.
