ABB 1SFB536068D1011 soft start control board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB 1SFB536068D1011 Soft Start Control Board Product Documentation

1. Product Description
The ABB 1SFB536068D1011 is a Soft Start Control Board specifically designed for industrial automation and motor control applications. As a core component of ABB soft starters, this control board is primarily used to control the smooth starting and stopping of three-phase asynchronous motors, reducing starting current impact and mechanical stress. It adopts advanced microprocessor technology and thyristor control technology to achieve precise voltage and current regulation, making it suitable for various industrial scenarios requiring smooth starting and stopping.

2. Detailed Parameters

3. Product Advantages and Features
3.1 Smooth Starting and Stopping: Achieves smooth motor starting and stopping through precise voltage and current control, reducing mechanical stress and grid impact.
3.2 Multiple Starting Modes: Supports various starting methods such as voltage ramp start, current limit start, and kick start, adapting to different load requirements.
3.3 Comprehensive Protection: Includes phase loss protection, overcurrent protection, overheating protection, start timeout protection, and other complete protection functions to ensure system and motor safety.
3.4 High-Precision Control: Uses microprocessor technology to sample voltage and current in real-time, calculating optimal starting parameters for precise control.
3.5 Flexible Configuration: Offers multiple parameter settings (nearly 30 parameters), supporting panel operation, external terminal control, and other control methods.
3.6 Easy Integration: Supports RS485 communication and Modbus protocol, facilitating integration with upper-level computers or other automation equipment.

4. Application Fields
4.1 Industrial Automation: Used for production line automation control, machinery equipment control, etc., achieving smooth motor starting and stoppin.
4.2 Pump and Fan Control: Applied in centrifugal pumps, fans, and other equipment control to reduce water hammer and mechanical stress during starting and stopping.
4.3 Air Compressors and Compressors: Used for starting control of air compressors and compressors, reducing starting current impact on the grid.
4.4 Power Systems: Used for auxiliary equipment control in power plants and substations, achieving smooth motor starting and stopping.
4.5 Infrastructure: Used for motor control in public infrastructure such as building automation and water treatment facilities37.
