ABB 3BHE003688R0101 UFC784AE101 circuit board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB 3BHE003688R0101 UFC784AE101 Circuit Board – Product Information

1. Product Overview

The ABB 3BHE003688R0101 UFC784AE101 Circuit Board is a core electronic module used in ABB control systems and automation equipment for signal processing, data transmission, and control logic operations.
It features industrial-grade design for stable and reliable operation, suitable for critical control applications in power generation, substations, and industrial automation systems.

2. Technical Specifications

• Model: 3BHE003688R0101

• Module Name: UFC784AE101 Circuit Board

• Type: Control/Signal Processing Circuit Board

• Operating Voltage: 24 V DC

• Power Consumption: Max 15 W

• Input Interfaces: Multiple digital/analog inputs

• Output Interfaces: Multiple digital/analog outputs

• Communication Interfaces: Supports CAN, Profibus, Ethernet (depending on system configuration)

• Processing Capability: Industrial-grade microcontroller, supporting real-time control and data processing

• Operating Temperature: 0 ℃ to +55 ℃

• Storage Temperature: -20 ℃ to +70 ℃

• Humidity: 5%–95%, non-condensing

• Protection Class: IP20

• Mounting: Rack-mounted or DIN rail installation

• Dimensions: Approx. 200 × 120 × 40 mm

• Weight: Approx. 1.2 kg

• Certifications: CE, UL, RoHS

3. Features and Advantages

1. Industrial-grade stability ensures reliable long-term operation in complex environments.

2. Multi-functional interfaces support multiple digital and analog I/O for system integration.

3. High-performance processing with built-in microcontroller for real-time data processing and control logic operations.

4. Modular design enables easy installation, removal, and maintenance.

5. Low power consumption for energy-efficient continuous industrial operation.

6. High compatibility supporting multiple industrial communication protocols for easy system integration.

4. Application Areas

• ABB automation control systems

• Power generation and substation control systems

• Industrial production line control and monitoring

• Data acquisition and remote monitoring systems

• Industrial automation equipment signal processing

5. Precautions

1. Install and wire the board only when power is off.

2. Ensure input voltage meets specifications to prevent damage.

3. Maintain proper ventilation to prevent overheating.

4. Avoid long-term use in high-humidity, dusty, or corrosive environments.

5. Regularly inspect wiring and mounting to ensure proper contact.

6. Operation and maintenance should be performed by qualified electrical personnel.
