ABB 3BHB019719R0101 GVC736BE101 Insulated Gate Commutated Thyristor (IGCT) Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB 3BHB019719R0101 GVC736BE101 Insulated Gate Commutated Thyristor (IGCT) Module – Product Information

1. Product Overview

The ABB 3BHB019719R0101 GVC736BE101 IGCT Module is a high-power electronic device used in high-performance inverters, power drives, and industrial automation systems.
It features fast switching, high current carrying capability, and high reliability, suitable for efficient energy conversion and control in high-power electronic systems.

2. Technical Specifications

• Model: 3BHB019719R0101

• Module Name: GVC736BE101

• Type: Insulated Gate Commutated Thyristor (IGCT) Module

• Rated Voltage: 3.3 kV

• Rated Current: 3,500 A

• Switching Speed: Fast, typical turn-off time < 5 µs

• Forward Voltage Drop: Approx. 1.7 V

• Power Loss: Depends on system configuration

• Operating Temperature: -40 ℃ to +125 ℃

• Storage Temperature: -40 ℃ to +125 ℃

• Insulation Class: Class F

• Mounting: Bolt-fixed, suitable for modular heatsink installation

• Dimensions: Approx. 160 × 120 × 50 mm

• Weight: Approx. 1.8 kg

• Certifications: CE, UL

3. Features and Advantages

1. High power handling supports high current and voltage applications.

2. Fast switching characteristics with typical turn-off time < 5 µs, suitable for high-frequency power conversion.

3. Low forward voltage drop improves efficiency and reduces energy loss.

4. High reliability with industrial-grade design for long service life.

5. Modular design for easy installation, replacement, and maintenance.

6. Rugged performance tolerates high temperature, vibration, and harsh industrial conditions.

4. Application Areas

• High-performance industrial inverters

• High-power electric drives

• Generator excitation systems

• Power electronic converters and HVDC systems

• Industrial automation and high-power control systems

5. Precautions

1. Install and wire the module only when power is off.

2. Do not exceed the module’s rated current and voltage to prevent damage.

3. Ensure proper cooling to prevent overheating.

4. Avoid long-term use in high-humidity, dusty, or corrosive environments.

5. Module operation and maintenance should be performed by qualified electrical engineers.

6. Avoid direct mechanical shock or strong vibration exposure.

The structure and details of the product：
