ABB TB82PH2110110 pH / ORP / pION Transmitter

4. Product Overview

   The ABB model TB82PH2110110 from the TB82PH series is a loop-powered, two-wire transmitter designed for pH, ORP (oxidation-reduction potential) and pIon (ion-specific) measurements. It offers digital communications options (HART, FOUNDATION Fieldbus, PROFIBUS PA) and is suitable for industrial use in harsh or hazardous environments (NEMA 4X / IP65 rated). The transmitter features an intuitive user interface with menu-guided setup, dual displays (primary measurement plus selectable secondary display) and is designed for straightforward calibration and maintenance.

   Key Specifications

   • Type: 2-wire pH / ORP / pIon transmitter.

   • Input sensor types:

     • pH: glass electrodes, antimony (Sb), custom iso-potential or asymmetric potential.

     • ORP: platinum (Pt), gold (Au).

     • pIon: e.g. sodium (Na⁺), chloride (Cl⁻), sulfide (S²⁻), etc.

   • Measuring ranges:

     • pH: 0 to 14 pH (extendable to –2 to +16 pH).

     • ORP / pIon: ±1999 mV.

   • Temperature compensation / display:

     • Temperature display range: –20 °C to 300 °C (–4 °F to 572 °F).

     • Compensation types: Pt100 RTD or 3 kΩ Balco.

     • Compensation modes: manual Nernst, standard automatic Nernst, automatic Nernst with solution coefficient.

   • Accuracy / repeatability:

     • pH display: ±0.01 pH.

     • ORP display: ±1 mV.

     • pIon display: ±1 mV.

   • Output signals:

     • Analog version: isolated 4-20 mA output (linear or nonlinear configurable).

     • Digital communication versions: HART / FOUNDATION Fieldbus / PROFIBUS PA.

   • Power supply:

     • Analog or HART versions: 14.0 to 53 VDC (14.0 to 42 VDC for certified hazardous-area versions).

     • FOUNDATION Fieldbus / PROFIBUS PA versions: 9–32 VDC (non-I.S.); 9–24 VDC (I.S.).

   • Environmental / protection:

     • Operating temperature: –20 °C to +60 °C (–4 °F to 140 °F); Storage: –40 °C to +70 °C (–40 °F to 158 °F).

     • Humidity: up to 95% RH.

     • Enclosure rating: NEMA 4X / IP65, aluminum alloy with powder-coated finish.

   • Dimensions & weight:

     • Height × Width × Depth: 144.0 × 144.0 × 171.0 mm (5.67 × 5.67 × 6.73 in).

     • Panel cut-out: 135.4 (+1.3 / –0.8) mm × 135.4 (+1.3 / –0.8) mm.

     • Weight: approx. 1.9 kg (4.2 lb); with pipe-mount hardware approx. 3.4 kg (7.5 lb).

   • Certifications / explosion protection:

     • ATEX Category II 1G; Ex ia, Zone 1, Group IIC, T4 when used with proper barriers.

     • CSA, FM, FISCO compliant.

   • Other features:

     • Built-in lightning suppressor: suppresses 10 successive 8×20 µs pulses with up to 20 kA peak.

     • Programmable 3-digit security code to prevent unauthorized configuration or calibration changes.

     • Adjustable damping (0.0 to 99.9 s) to filter process noise.

   Advantages & Features

   • Cost-efficient installation: Two-wire loop powering reduces wiring and installation cost; suitable for hazardous-area mounting.

   • User-friendly interface: Menu-guided operation, intuitive Smart-Keys and dual-display (primary measurement + secondary selectable) simplify setup and calibration.

   • Modern communication options: Supports analog output and digital protocols (HART, FF, PROFIBUS PA) allowing integration with advanced automation systems.

   • Robust industrial design: High-protection enclosure (NEMA 4X / IP65), explosion-proof or intrinsically safe versions available for harsh environments.

   • Sensor compatibility: Accepts a wide variety of pH, ORP and ion-selective sensors, including ABB’s own and many third-party sensors, providing flexibility.

   • Advanced diagnostics: Continuously monitors itself and sensor status (e.g., broken electrode, high reference impedance, cable faults) and provides fault notification and remote diagnostics via fieldbus.

   • Flexible calibration: Supports both one-point and two-point calibration; during two-point calibration the analog output can be held at a defined level.

   • Noise suppression: Adjustable damping allows for smoother output in noisy process environments.

   Typical Applications

   • Water and wastewater treatment: pH/ORP monitoring is critical for neutralization, disinfection, effluent compliance.

   • Chemical industry: Acid/base processes, reaction vessels, ion-specific measurement (pIon) in manufacturing.

   • Power generation & utilities: Monitoring pH/ORP in boiler feed-water, cooling circuits, flue gas desulfurization systems.

   • Pulp & paper industry: pH/ORP monitoring in pulp bleaching stages, dye/waste liquor treatment.

   • Food & beverage / pharmaceutical: Clean-in-place (CIP) loops, pH control in production, ion monitoring where required.

   • Heavy industry: Metal finishing, plating, mining operations where pH/ORP/ion measurements are required.

   Precautions / Notes

   • Ensure power supply voltage is within specified range (14–53 VDC, or 14–42 VDC for certified versions) to avoid communication/output issues.

   • For digital communication versions (HART/FF/PA) carefully follow wiring and bus architecture rules (termination resistors, isolation, etc.).

   • Sensor selection/installation is critical: for pH/ORP sensors ensure reference electrode is intact, ground rod present to avoid ground-loop errors or diagnostic alarms.

   • In high-electrical-noise or lightning-prone environments, use properly shielded cable, good grounding and take advantage of built-in lightning suppressor.

   • Regular calibration and sensor maintenance are recommended to maintain measurement accuracy and reliability.

   • Avoid installation in extreme ambient conditions beyond the rated –20 °C to +60 °C or prolonged exposure to condensation/humidity exceeding spec.

   • When installed in hazardous zones, confirm that the model carries the required certification (e.g., ATEX Zone 1, Group IIC) and use appropriate barriers or intrinsically safe wiring as applicable.
