ABB 1SVR405612R7100 Pluggable Interface Relay

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 1SVR405612R7100 Pluggable Interface Relay is part of the ABB S2 relay series, providing reliable electrical isolation and control signal conversion. It is designed for automation control systems, PLC interfaces, and industrial equipment signal control. The pluggable design allows easy installation, maintenance, and modular expansion, ensuring flexibility and reliability in industrial control systems.

2. Technical Specifications (Typical)

• Model: 1SVR405612R7100

• Type: Pluggable Interface Relay

• Relay Type: Electromagnetic relay

• Contact Configuration: 2 NO (Normally Open)

• Contact Current: 8 A

• Contact Voltage: 250 V AC / 30 V DC

• Coil Voltage: 24 V DC (other voltages optional)

• Power Consumption: ~0.9 W

• Insulation Voltage: 2 kV AC (coil to contact)

• Mechanical Life: ≥10,000,000 operations

• Electrical Life: ≥100,000 operations (rated load)

• Mounting: DIN rail or pluggable socket

• Operating Temperature: -40 °C to +70 °C

• Protection Class: IP20

3. Advantages & Features

• Modular pluggable design: Allows quick installation, removal, and replacement, improving maintenance efficiency.

• High reliability: Industrial-grade design supports high-frequency switching and long-term operation.

• Standardized interface: Compatible with PLCs, controllers, and other modular systems.

• Electrical isolation: Provides safe coil-to-contact isolation for control system protection.

• Compact design: Saves space, ideal for control cabinet installation.

4. Typical Applications

• PLC and industrial automation system interfaces

• Signal conversion and expansion in control cabinets

• Industrial equipment switching control

• Building automation systems

• Motor starting and control circuits

• Process control and data acquisition systems

5. Installation & Operation Notes

1. Rated voltage and current matching: Ensure coil voltage and contact load current are within rated parameters.

2. Pluggable installation: Socket must be securely fixed to avoid poor contact.

3. Environmental conditions: Avoid high humidity, high temperature, and corrosive gases.

4. Correct wiring: Follow wiring diagrams strictly to prevent short circuits or overload.

5. Periodic inspection: Check relay operation and wiring regularly to ensure long-term reliability.
