ABB 1SDA051208R1 Molded Case Circuit Breaker

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 1SDA051208R1 Molded Case Circuit Breaker (MCCB) is part of the ABB S200 series, designed for overload, short-circuit, and undervoltage protection in low-voltage distribution systems. It features high reliability, long service life, and overload protection, suitable for industrial, commercial, and residential power protection and distribution systems.

2. Technical Specifications (Typical)

• Model: 1SDA051208R1

• Type: Molded Case Circuit Breaker (MCCB)

• Rated Current: 100 A

• Poles: 3P

• Rated Short-Circuit Breaking Capacity: 25 kA (IEC 60947-2)

• Rated Operational Voltage: AC 415 V / DC 250 V

• Trip Characteristic: B, C, D type selectable (standard C-type)

• Mechanical Life: ≥10,000 operations

• Electrical Life: ≥4,000 operations

• Mounting: Panel or DIN rail mounting

• Optional Accessories: Auxiliary contacts, alarm contacts, remote operation modules

• Operating Temperature: -25 °C to +60 °C

• Protection Class: IP20

3. Advantages & Features

• Reliable overload and short-circuit protection: Ensures circuit and equipment safety.

• Multi-pole design: Suitable for three-phase distribution and complex loads.

• Long service life: Extended mechanical and electrical life reduces maintenance cost.

• Modular design: Supports auxiliary contacts, remote operation, and alarm modules for functional expansion.

• Quick installation: Standardized design facilitates installation in control cabinets and distribution boards.

4. Typical Applications

• Low-voltage distribution in industrial plants

• Power distribution in commercial buildings and offices

• Residential and public building power protection

• Motor, pump, and fan circuit protection

• Power supply protection for automation equipment

• Data center and critical load protection

5. Installation & Operation Notes

1. Rated current matching: Select breaker rated current above load operating current.

2. Trip characteristic selection: Choose B/C/D type according to load characteristics.

3. Correct wiring: Ensure proper connection of power supply and load; avoid loose connections or short circuits.

4. Environmental conditions: Avoid humidity, dust, and corrosive gases; maintain proper ventilation.

5. Periodic inspection: Check breaker operation and wiring regularly to ensure long-term reliability.
