ABB A0801V2 Analog Output Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB A0801V2 Analog Output Module is an I/O module used in ABB industrial automation systems to convert digital control signals into standard analog signals (e.g., 0–10 V or 4–20 mA) for controlling valves, drives, regulators, or other field actuators. It features high precision, stability, and multi-functional output, widely applied in process control, industrial automation, and smart grid systems.

2. Technical Specifications (Typical)

• Model: A0801V2

• Type: Analog Output Module

• Output Type: Voltage or current output (selectable)

• Output Channels: 1 channel

• Output Range:

  • Voltage: 0–10 V

  • Current: 4–20 mA

• Resolution: 12-bit

• Load Capacity: Voltage output ≥ 2 kΩ, current output ≤ 500 Ω

• Accuracy: ±0.5%

• Update Rate: 10 ms (typical)

• Supply Voltage: 24 V DC

• Operating Temperature: -20 °C to +60 °C

• Protection Class: IP20

• Mounting: DIN rail mounting

• Compatible Systems: Works with ABB DCS, PLC, or controller systems

3. Advantages & Features

• High precision and stability: Ensures accurate analog signal output for process control.

• Multi-functional output: Supports both voltage and current outputs for flexible control.

• Fast response: High update rate ensures real-time control performance.

• High reliability: Industrial-grade design suitable for long-term continuous operation.

• Modular design: Can be combined with other I/O modules for system expansion and maintenance.

• Easy installation and maintenance: Standard DIN rail mounting facilitates field setup and replacement.

4. Typical Applications

• Industrial automation process control

• Fluid control systems (pumps, valves, actuators)

• HVAC system control

• Smart grid and distribution automation

• Motor speed or position regulation

• Data acquisition and control systems

5. Installation & Operation Notes

1. Load matching: Ensure voltage or current output load is within module specifications.

2. Correct wiring: Follow wiring diagram strictly to prevent short circuits or reverse connection.

3. Stable power supply: Use rated 24 V DC supply to ensure output accuracy.

4. Environmental conditions: Avoid humidity, dust, and corrosive gases; maintain proper ventilation.

5. System integration: Ensure compatibility of communication and signals when used with controllers or PLCs.
