A-B MPL-B580F-MJ72AA Servo Motor

Product Overview

The Allen-Bradley MPL-B580F-MJ72AA is an MP-Series low-inertia brushless AC servo motor designed for high-performance motion-control applications. It features a 460 VAC rating, 3000 RPM speed, 34 Nm continuous torque, multi-turn absolute feedback, keyed shaft, and no holding brake.

Key Technical Specifications

Rockwell lists the model as an active MP-Series MPL 480V AC rotary servo motor.

Advantages & Features

• Low-inertia design for fast acceleration and deceleration
• 34 Nm continuous torque with high peak torque capability
• High-resolution multi-turn absolute feedback
• 3000 RPM rated operating speed
• Keyed shaft for secure mechanical coupling
• Rotatable SpeedTEC DIN connector for flexible cable routing
• Designed for compact, high-performance motion-control systems
• Compatible with multiple Allen-Bradley Kinetix servo drive platforms

Applications

• Industrial automation
• Packaging machinery
• Material handling
• Robotics and motion systems
• CNC and machine tools
• Printing and converting equipment
• Automotive manufacturing
• Precision positioning systems

Important Notes

• Verify that the servo drive is compatible with the 460 VAC motor rating and the specific feedback system.
• This model does not include a holding brake.
• Use the correct Allen-Bradley motor power and feedback cables.
• Confirm shaft dimensions, mounting configuration, and connector orientation before installation.
• Proper grounding, shielding, and cable routing are recommended for reliable encoder and motor operation.
