A-B 1769-IF16C CompactLogix Analog Input Module

Product Overview

The Allen-Bradley 1769-IF16C is a 16-channel high-density analog current input module for CompactLogix and Compact I/O systems. It accepts 0–20 mA and 4–20 mA signals and is designed for high-density industrial measurement and control applications.

Key Technical Specifications

Technical specifications are based on Rockwell Automation documentation.

Advantages & Features

• 16 analog current input channels in a compact footprint
• Supports standard 0–20 mA and 4–20 mA industrial signals
• High-resolution 16-bit analog-to-digital conversion
• Multiple selectable input filter frequencies
• Built-in over-range and under-range diagnostics
• DIN-rail or panel mounting
• Compact design helps reduce control-panel space
• Suitable for high-density CompactLogix I/O systems

Applications

• Process automation
• Factory automation
• PLC-based control systems
• Pressure, flow and level monitoring
• Temperature and process transmitters
• Industrial instrumentation
• Chemical and manufacturing equipment
• Machine monitoring and control

Important Notes

• This module is specifically for current input signals; it does not provide the voltage-input ranges of the 1769-IF16V.
• Verify the required 0–20 mA or 4–20 mA signal type before installation.
• Do not exceed the specified input overload limits, as damage may occur.
• The module should be installed within the specified Compact I/O power-supply distance rating.
• Use appropriate shielded analog wiring for reliable signal transmission.
