- - Allen‑Bradley MPL-B4540F-SJ22AA MP-Series Low-Inertia AC Servo Motor

    Product Overview

    This is a Rockwell Automation MP‑Series permanent magnet low‑inertia brushless rotary servo motor, matched with Kinetix 5500/5700/7000 servo drives for high‑precision multi‑axis motion control. It adopts IEC metric frame design, single‑turn high‑resolution encoder feedback, keyed solid shaft, no holding brake, and bayonet circular connectors.

    MPL-B4540F-SJ22AA Servo Motor

    Core Specifications

    Frame size: 130 mm (4‑inch magnetic stack length)

    Rated power: 3.0 kW / 3.5 HP

    Rated speed: 3000 RPM

    Rated continuous torque: 10.2 N·m

    Supply voltage: 460/480 VAC three‑phase

    Rated current: 9.1 A

    Feedback: Single‑turn high‑resolution encoder

    Shaft: Keyed shaft, no shaft seal

    Brake: Without holding brake

    Connector: Bayonet circular connector, right‑angle rotatable 180°

    Mounting: Standard IEC FF flange mounting

    Net weight: 9.53 kg

    Operating temperature: 0 ℃ ~ 40 ℃, IP65 shaft side, IP50 motor housing

    Certifications: CE, UL, RoHS compliant

    Main Functions

    Deliver fast dynamic torque output for positioning, speed and closed‑loop motion control

    High‑resolution single‑turn encoder provides real‑time position feedback to servo drive for micron‑level positioning accuracy

    Low rotor inertia supports rapid acceleration/deceleration for high‑cycle automation cycles

    Smooth sinusoidal torque output eliminates cogging for stable operation at low speeds

    Key Advantages

    Low‑inertia rotor design enables ultra‑fast response and short settling time

    Compact high power density saves installation space inside equipment

    Rotatable right‑angle bayonet connector simplifies wiring layout

    Rugged industrial housing withstands dust, splash and workshop vibration

    Full compatibility with all Rockwell Kinetix servo drive platforms
