Allen‑Bradley 800T-B2A 2-Position Maintained Selector Switch Operator

Product Overview

Core Specifications

• Mounting cutout: Standard 30.5mm panel hole
• Operator type: 2-position maintained/latching standard knob, stays in selected position after release
• Housing material: Zinc alloy metal front, NEMA Type 4/13 dustproof & splash-proof protection
• Compatible contact blocks: 800T-XA series (1NO+1NC standard combination)
• Electrical rating: Max 600V AC/DC, thermal current 10A; AC-15 / DC-13 utilization category
• Mechanical lifespan: Minimum 10 million operation cycles
• Operating temperature: -40°C ~ +55°C; storage range -40°C ~ +85°C
• Vibration & shock resistance: Withstands 10G vibration, 100G impact shock
• Certifications: UL, CSA, CE, CCC, EAC certified
• No built-in lamp circuit, non-illuminated design

Main Functions

1. Provide two stable selectable operating states for manual mode switching (Auto/Hand, Run/Stop, Local/Remote etc.)
2. Match stacked auxiliary contact blocks to output separate digital signals to PLC, contactor interlock and indicator circuits
3. Lock each position mechanically to avoid accidental state shift during equipment operation
4. Deliver reliable manual selection for equipment operation mode switching and circuit interlock control

Key Advantages

• Robust all-metal front casing adapts to dusty, humid and oily harsh workshop environments
• Latching structure maintains circuit state without continuous manual holding
• Modular split design, easy to assemble/disassemble contact blocks for on-site wiring modification
• Wide voltage and current compatibility fits all standard industrial low-voltage control circuits
• High mechanical durability reduces replacement frequency under frequent switching cycles
