Allen-Bradley H-4050-P-H04AN Servo Motor (H-Series Brushless Servo)





The Allen-Bradley H-4050-P-H04AN is a legacy H-Series low-inertia brushless AC servo motor used in high-performance motion control systems. It works together with Allen-Bradley servo drives (such as 1398 Ultra or legacy Kinetix/BRU systems) to provide precise position, speed, and torque control for industrial machines.

This is a servo motor (mechanical + electromagnetic actuator), not a drive or controller.

Key Specifications

• Model: H-4050-P-H04AN
• Brand: Allen-Bradley (Rockwell Automation)
• Series: H-Series Low Inertia Servo Motor
• Type: Brushless AC Servo Motor
• Frame Size: 4050
• Encoder: ~2000 line optical encoder feedback
• Brake Option: 24V DC holding brake (built-in in H04AN configuration)
• Design: Low inertia rare-earth (neodymium) rotor for fast acceleration
• Cooling: Natural convection (typical H-series design)
• Mounting: NEMA 56C flange style
• Protection: Industrial sealed housing (varies by configuration)

What it does (simple explanation)

Servo Drive (1398 / Kinetix / Ultra)
↓
H-4050-P-H04AN Servo Motor
↓
Mechanical motion (shaft rotation)
↓
Machine axis movement

It converts electrical servo drive signals into precise mechanical motion.

Main Functions

• High-precision motion control (positioning systems)
• Rapid acceleration / deceleration response
• Closed-loop feedback via encoder
• Torque-controlled motion output
• Works in synchronized multi-axis systems

Key Features

• Low inertia rotor for fast dynamic response
• High-resolution encoder feedback (~2000 PPR class)
• Optional 24V holding brake for load holding
• High torque-to-size ratio
• Designed for servo drive systems (not standalone use)
• Industrial-grade rugged construction

Applications

• CNC machinery
• Robotics
• Packaging machines
• Printing equipment
• Automated assembly lines
• Material handling systems
• High-speed positioning systems
