A-B 2711P-T12W22D9P HMI Panel

Allen-Bradley 2711P-T12W22D9P PanelView Plus 7 Performance HMI





The Allen-Bradley 2711P-T12W22D9P is a PanelView Plus 7 Performance HMI terminal used for machine visualization and operator control in modern Ethernet-based PLC systems (ControlLogix / CompactLogix).

It is a 12.1-inch widescreen industrial touchscreen HMI designed for FactoryTalk View ME applications.

Key Specifications

• Model: 2711P-T12W22D9P
• Series: PanelView Plus 7 Performance
• Brand: Allen-Bradley (Rockwell Automation)
• Display: 12.1" TFT widescreen
• Resolution: 1280 × 800 (WXGA)
• Input: Touchscreen (resistive industrial type)
• Power Supply: 24V DC (18–30V DC range)
• Communication:
  • EtherNet/IP (dual Ethernet ports in most configurations)
• Operating System: Windows-based embedded platform (FactoryTalk View ME runtime)
• Memory: Flash + RAM for HMI applications
• Mounting: Panel mount (industrial enclosure front IP/NEMA rated)

What it does (simple explanation)

PLC (ControlLogix / CompactLogix)
↓
EtherNet/IP network
↓
2711P-T12W22D9P HMI Panel
↓
Operator interacts with machine

It is used to:

• Display machine status
• Show alarms and fault messages
• Control start/stop operations
• Adjust process parameters
• Monitor PLC data in real time

Main Functions

• Industrial machine visualization (HMI screens)
• Operator control interface for PLC systems
• Alarm monitoring and event display
• Recipe / parameter management
• Data logging and trend display
• Ethernet communication with controllers

Key Features

• 12.1-inch widescreen high-resolution display
• Modern PanelView Plus 7 platform
• EtherNet/IP communication (fast PLC integration)
• Dual Ethernet support for network flexibility (DLR/linear/star)
• FactoryTalk View ME runtime environment
• Rugged industrial design for harsh environments
• USB and SD card support (for project transfer/logging depending version)

Applications

• Factory automation systems
• Packaging machinery
• Process control systems
• Conveyor systems
• Robotics workstations
• OEM machine interfaces
