A-B 80190-520-01-R Drive Control Board

Product Description

The Allen-Bradley 80190-520-01-R is a Control Board / CLGD (Current Loop Gate Driver) Board manufactured by Rockwell Automation (Allen-Bradley). It is designed for use in SMC Flex Medium Voltage Motor Controllers and related motor control equipment, providing control and communication functions within the power control system.

This board is a PCB assembly component used inside industrial motor controllers. It provides gate drive and control functions for power semiconductor switching circuits, helping regulate motor starting and protection operations.

Detailed Specifications

Advantages & Features

• Original Allen-Bradley industrial control board
• Designed for SMC Flex soft starter systems
• Provides reliable SCR gate control functionality
• Supports high-speed fiber optic communication
• Industrial-grade PCB design for demanding environments
• Suitable for equipment maintenance and replacement
• Helps restore existing motor control systems without complete controller replacement

Applications

• Medium Voltage Motor Starters
• SMC Flex Soft Starter Systems
• Industrial Motor Control Equipment
• Pump and Fan Systems
• Mining Equipment
• Oil & Gas Facilities
• Power Generation Systems
• Heavy Industrial Machinery

Precautions

• Confirm compatibility with the exact SMC Flex controller model before installation.
• Verify board revision and replacement part number.
• Disconnect power completely before replacing the PCB.
• Handle the circuit board using proper ESD protection.
• Check fiber optic connections before system startup.
• This is a replacement control board component, not a complete motor controller.
