Allen-Bradley 2094-BC07-M05-S Kinetix 6000 Servo Drive Power Module

Product Description

Allen-Bradley 2094-BC07-M05-S is a Kinetix 6000 Integrated Axis Module (IAM) from Rockwell Automation. It combines the converter section and inverter section in one module, providing power conversion and servo motor control for multi-axis motion control systems. It supports Safe Torque-Off (STO) functionality and is designed for high-performance industrial automation applications.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 2094-BC07-M05-S
• Series: Kinetix 6000
• Product Type: Integrated Axis Module / Servo Drive Power Module
• Input Voltage: 360…480 VAC, 3-phase
• Input Voltage Range: 324…528 VAC rms
• Output Bus Power: 45 kW
• Inverter Current Rating: 48 A
• DC Bus Voltage: 458…747 VDC
• Input Frequency: 47…63 Hz
• Internal Shunt Continuous Power: 200 W
• Internal Shunt Peak Power: 22.5 kW
• Efficiency: Approx. 97%
• Safety Function: Safe Torque-Off (STO)
• Mounting: Kinetix 6000 power rail system
• Weight: Approx. 10.1 kg

Advantages & Features

• Integrated converter and inverter design reduces cabinet space
• High-performance servo motor control capability
• Supports multi-axis motion control systems
• Provides precise speed, torque, and position control
• Built-in Safe Torque-Off function improves machine safety
• High efficiency and reliable industrial operation
• Compatible with Allen-Bradley Kinetix 6000 motion platforms

Applications

• CNC machine tools
• Industrial robots
• Packaging machinery
• Semiconductor equipment
• Automated assembly systems
• Material handling equipment
• Precision motion control systems

Notes

• Verify compatibility with Kinetix 6000 power rail and axis modules before installation
• Confirm motor, feedback device, and parameter configuration
• Ensure correct AC input voltage before powering on
• Allow sufficient ventilation for heat dissipation
• Disconnect power and wait for DC bus discharge before maintenance
• This model has been discontinued by Rockwell Automation; check replacement options if upgrading existing systems
