A-B 800T-FXT6A1 Push Button Operator

Allen-Bradley 800T-FXT6A1 Push Button Operator (30 mm Mushroom Push-Pull / Twist Release)





The Allen-Bradley 800T-FXT6A1 is a 30 mm industrial push button operator from the 800T heavy-duty control device series. It is a maintained push-pull (or push-pull with twist release) mushroom head operator, widely used for industrial machine control and emergency stop style control stations.

Product Information

• Brand: Allen-Bradley (Rockwell Automation)
• Series: 800T / 800T PB
• Model: 800T-FXT6A1
• Type: Push Button Operator (mechanical actuator only)
• Size: 30 mm mounting hole
• Actuation: Push-pull / twist release (maintained type)
• Head type: Mushroom head (red)
• Contact blocks: Installed separately (1NO + 1NC typical configuration)

What it actually is

This is only the operator head (mechanical part). It does NOT include electrical contacts by default.

It works like this:

• Operator (this part) = physical button you press
• Contact block (rear module) = converts movement into electrical signal

So it is part of a modular industrial control station system.

System Role (Simple)

Human operator
→ presses/pulls button (800T-FXT6A1)
→ contact block behind it switches NO/NC contacts
→ PLC or control circuit receives signal
→ machine starts / stops / resets

Key Features

• Heavy-duty industrial push-pull mechanism
• Maintained position (stays in until reset)
• Twist-to-release safety function
• 30 mm standard industrial mounting size
• Compatible with 800T contact blocks
• High mechanical durability (industrial grade)
• Suitable for harsh environments

Typical Applications

• Machine start/stop stations
• Emergency stop / safety control panels (when configured as E-stop assembly)
• Conveyor control systems
• Industrial motor control panels
• Production line operator stations
• Heavy machinery control interfaces

Advantages

• Very rugged industrial design (800T heavy-duty series)
• Modular system (operator + contact blocks separated)
• Long mechanical life cycle (high durability)
• Suitable for vibration and harsh environments
• Standardized 30 mm panel cutout

Important Notes

• This is NOT a complete push button switch assembly ❌
• Electrical contacts are separate parts (must be ordered separately)
• Not a PLC module ❌
• Not an electronic device ❌
• It is a mechanical operator for industrial control circuits ✔

Precautions

• Must match correct 800T contact blocks and accessories
• Incorrect contact block pairing may cause wrong function
• Ensure correct panel cutout (30.5 mm typical)
• Maintain proper safety configuration if used as emergency stop
• Mechanical wear possible over long cycles in harsh use
