A-B 592-EC2DC Electronic Overload Relay

Allen-Bradley 592-EC2DC Electronic Overload Relay (E3 Plus Motor Protection Module)





The 592-EC2DC is an Allen-Bradley E3 Plus electronic overload relay used for motor protection in industrial motor starter systems. It is designed to protect AC motors (single or three-phase) against overload, phase loss, and abnormal current conditions.

Product Information

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 592-EC2DC
• Series: Bulletin 592 / E3 Plus
• Type: Electronic (solid-state) overload relay
• Current range: 9 – 45 A
• Mounting: Motor starter / contactor mounted (Size 0–2 systems)
• Function: Motor protection + monitoring + trip control

What it actually does

This module is used to:

• Continuously monitor motor current (RMS sensing)
• Detect abnormal conditions:
  • overload (overcurrent over time)
  • phase loss
  • imbalance
  • ground fault (depending configuration)
• Trip the contactor coil circuit to stop the motor
• Provide diagnostic feedback to PLC / control system
