A-B 700-HF32Z24 Control Relay

Product Description

Allen-Bradley 700-HF32Z24 is a 700-HF Series General Purpose Miniature Square Base Control Relay manufactured by Rockwell Automation. It is a compact electromechanical relay designed for industrial control circuits, PLC interface applications, signal switching, and general-purpose automation control.

This relay features a 24V DC coil, DPDT (2 Form C) contacts, and plug-in mounting design, providing reliable switching performance in industrial control panels.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 700-HF32Z24
• Product Type: General Purpose Control Relay
• Series: 700-HF
• Relay Type: Electromechanical Miniature Relay
• Contact Configuration: DPDT (2 CO / 2 Form C)
• Coil Voltage: 24V DC
• Contact Rating: 12 A
• Contact Material: AgCdO (Silver Cadmium Oxide)
• Connection Type: Plug-in Connection
• Mounting Type: Socket Mount
• Operating Temperature: -40…70 °C
• Protection: IP20 (with guarded terminal socket)
• Dimensions: Approx. 20.7 × 44.2 × 27.7 mm

Functions

• Provides electrical isolation between control circuits
• Switches AC/DC loads through relay contacts
• Interfaces PLC outputs with higher-power devices
• Controls contactors, solenoids, alarms, and indicators
• Provides signal conversion and circuit switching functions
• Used as an interposing relay in automation systems

Advantages & Features

• Compact miniature relay design
• Reliable electromechanical switching
• Dual change-over contacts for flexible wiring
• 24V DC coil suitable for industrial control systems
• Plug-in structure for easy replacement and maintenance
• High switching reliability for automation applications

Applications

• PLC control cabinets
• Industrial automation equipment
• Motor control circuits
• Machine control systems
• Factory production lines
• Signal isolation circuits
• Control panel interface applications

Notes

• 700-HF32Z24 is a control relay, not a safety relay
• Requires a compatible relay socket for installation
• Confirm coil voltage (24V DC) before replacement
• Check contact rating and load type before use
• Avoid exceeding rated switching current
