A-B 193-ECM-DNT DeviceNet Communication Module

Product Description

Allen-Bradley 193-ECM-DNT is an E300 Electronic Overload Relay DeviceNet Communication Module manufactured by Rockwell Automation. It is designed to provide DeviceNet network communication for E300/E200 electronic overload relay systems, allowing motor protection devices to communicate with PLCs and industrial control systems.

This module is part of the modular E300 motor protection platform and provides access to overload relay status, diagnostics, configuration parameters, and real-time motor protection information through a DeviceNet network.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 193-ECM-DNT
• Product Type: DeviceNet Communication Module
• Series: E300 / E200 Electronic Overload Relay
• Communication Protocol: DeviceNet
• Supply Voltage: 24V DC
• Network Connector: 5-pin DeviceNet connector
• Protection Rating: IP20
• Mounting: Modular attachment to E300 overload relay system
• Compatible Systems: Allen-Bradley E300/E200 Overload Relays (193/592 series)

Functions

• Provides DeviceNet communication between E300 overload relays and PLC systems
• Transfers motor operating data and protection status
• Allows remote configuration of overload relay parameters
• Provides fault, warning, and diagnostic information
• Supports integration with Allen-Bradley automation networks
• Enables intelligent motor management functions

Advantages & Features

• Supports intelligent motor protection communication
• Provides real-time motor diagnostics
• Simplifies connection between overload relays and PLC systems
• Modular design for easy installation and replacement
• Reduces traditional hardwired control connections
• Compatible with Rockwell Automation DeviceNet networks

Applications

• Motor Control Centers (MCC)
• Industrial automation systems
• Pump and fan control
• Conveyor systems
• Machine tools
• Factory production lines
• Process control equipment

Notes

• 193-ECM-DNT is a communication module, not a complete overload relay
• Requires compatible E300 sensing module and control module for full motor protection operation
• Requires 24V DC power supply
• Confirm DeviceNet node address and network parameters before commissioning
• Verify compatibility with existing E300 components
