Allen-Bradley 5094-OB16 | Digital Output Module

Specifications

• Channels: 16 discrete outputs
• Output Type: Sourcing (PNP)
• Operating Voltage: 10–32 VDC (24 VDC nominal)
• Output Current: 0.5 A per channel, 4 A total maximum
• Backplane Power: 15 VDC, 120 mA
• Onboard Filter: Configurable response delay
• Isolation: Reinforced insulation, 250 V continuous
• Indicators: Module status, power and individual channel LED status
• Mounting: DIN rail / panel mount
• Enclosure Rating: IP20
• Operating Temperature: −40 °C to +70 °C
• Communication: Gigabit EtherNet/IP, supports DLR, PRP topologies
• Features: Hot-swap capable, removable terminal base
• Certifications: UL, CE, RCM, CCC, ABS

Key Features

1. High-density 16 outputs for space-efficient cabinet layout.
2. PNP sourcing design compatible with standard DC actuators.
3. Hot-swap function allows module replacement without system shutdown.
4. Multiple network topologies for flexible industrial networking.
5. Robust construction for wide temperature range industrial use.

Applications

• Control of solenoids, relays, indicators and small DC actuators
• Assembly lines, conveyors, packaging machinery
• General factory automation and process control systems
