A-B 5094-IB16 Digital Input Module

Allen‑Bradley 5094‑IB16 | FLEX 5000 Digital Input Module

Specifications

• Input Channels: 16 discrete inputs
• Input Type: Sinking (NPN)
• Voltage Range: 10–32 VDC (nominal 24 VDC)
• Input Current: 2–8 mA per channel
• Backplane Power: 15 VDC, 80 mA max
• Sensor/Actuator Power: 18–32 VDC, 135 mA max (module)
• Input Filter: Hardware 98 µs + user‑selectable 0–50 ms
• Isolation: Reinforced insulation, 250 V continuous
• Indicators: Module status, SA power, 16× I/O status LEDs
• Enclosure: IP20 (open‑style)
• Mounting: DIN rail or panel mount
• Temperature: −40 °C to +70 °C
• Certifications: UL, CE, RCM, CCC, ABS
• Dimensions (H×W×D): ~94 × 69 × 50 mm
• Weight: ~0.28 kg

Key Features

1. High‑density 16‑point: Compact, saves panel space.
2. Sinking input (NPN): Directly connects to sensors with NPN outputs.
3. Gigabit EtherNet/IP: 1 Gb, supports DLR, PRP, star, linear topologies.
4. Hot‑swap capable: Replace module without powering down the rack.
5. Removable terminal base: Simplifies wiring and maintenance.

Applications

• Factory automation, assembly lines
• Material handling, conveyors
• Packaging machinery
• Process automation (water/wastewater, HVAC)
• Machine tools, general‑purpose discrete input monitoring
