Allen‑Bradley 5069-L340ER CompactLogix 5380 Controller

Product Overview

Core Technical Specifications

Performance & Memory

• User program memory: 4 MB
• Maximum local Compact 5000 I/O modules: 31
• Maximum supported EtherNet/IP network nodes: 90
• Integrated motion axes: 0 (motion model suffix ERM supports 20 CIP motion axes)
• Processor: Quad-core high-speed architecture for fast logic scans and I/O refresh
• Non-volatile storage: SD card slot compatible with 1784-SD1/SD2 industrial memory cards for program backup, firmware storage and data logging
• Task configuration: Up to 32 continuous tasks, max 1000 routines per task

Communication Interfaces

• Dual 10/100/1000 Mbps Gigabit EtherNet/IP RJ45 ports
  • Supported topologies: DLR Device Level Ring, Linear, Star, Dual-IP network isolation
  • Carries real-time I/O data, HMI traffic, CIP safety signals and remote programming access
• USB 2.0 Type-B port: Temporary connection for offline programming, firmware download and online debugging (no permanent field wiring allowed)
• Isolation rating: 300 V continuous insulation between Ethernet circuits and backplane/DC power circuits; no isolation between the two Ethernet ports

Electrical Power Ratings

• MOD logic input power: 18–32 VDC, rated 450 mA, peak inrush 850 mA (125 ms duration)
• SA auxiliary universal power input: 0–32 VDC / 0–240 VAC 47–63 Hz
• Maximum power dissipation: 8.5 W (29 BTU/hr)
• Standard configuration includes supercapacitor short-term memory backup; variant -NSE removes supercap backup

Mechanical & Environmental Parameters

• Mounting: Horizontal installation only on standard 35 mm DIN rail (EN50022)
• Overall dimensions (H×W×D): 143.97 × 98.10 × 136.81 mm
• Net weight: ~0.768 kg (1.693 lb)
• Enclosure rating: IP20, for indoor control cabinet installation only
• Operating temperature: 0 °C ~ +60 °C; storage temperature: -40 °C ~ +85 °C
• Relative humidity: 5%–95% non-condensing
• Shock & vibration: Compliant with IEC 60068 industrial test standards
• Front panel indicators: Multi-color LED status for controller Run/Fault, Ethernet link/activity, backplane module errors

Global Certifications

Main Functions

1. Complex Discrete & Analog Logic Execution



   Supports Ladder Diagram, Function Block Diagram, Structured Text, Sequential Function Chart programming languages to control local Compact 5000 digital/analog I/O and distributed remote field devices. Executes complex interlock, batch sequencing and PID process regulation logic.
2. Dual Gigabit EtherNet/IP Redundant Network Gateway

• Dual-IP mode physically separates OT control network and IT enterprise network without extra external switches
• DLR ring topology delivers single cable break redundancy to eliminate unplanned production downtime
• Simultaneously exchanges real-time I/O signals, HMI screen data, fault alarms and production batch data with drives, HMIs, safety devices and remote I/O racks

3. Comprehensive System Diagnostics & Fault Logging



   Front-panel status LEDs provide instant visual health indication; detailed fault codes, event logs and module failure records are uploaded to HMI for remote troubleshooting and equipment maintenance traceability.
4. Built-in Industrial Cybersecurity Suite

• Encrypted, digitally signed firmware to prevent unauthorized tampering
• Role-based access control for program editing and online modification
• Full operation change logging and unauthorized access detection
• Configurable network security policies to isolate control networks from office IT infrastructure

5. Offline Program Backup & Rapid System Recovery



   SD card slot stores complete controller logic, tag database, I/O configuration and firmware files. When replacing a failed controller, the unit can auto-restore all configurations without re-downloading programs from a programming workstation.
6. Distributed Remote I/O Management



   Drives large-scale remote Compact 5000 I/O racks over EtherNet/IP, shortening long-distance field wiring and reducing electromagnetic interference for scattered production stations and process skids.

Key Advantages

• Quad-core high-speed processor delivers significantly faster scan performance compared to legacy 1769 CompactLogix controllers, suitable for high-cycle complex machine control
• Dual integrated 1 Gbps Ethernet ports eliminate the need for external network switches to implement network isolation or ring redundancy
• Compact slim DIN rail form factor minimizes cabinet space occupation for mid-size integrated control panels
• Unified Studio 5000 Logix Designer programming environment, fully consistent with ControlLogix large-scale PLC platforms for seamless project migration
• Wide hazardous location certification supports chemical, water treatment, oil & gas light industrial cabinet deployments
• Highly modular expandable local I/O rack, flexible to add analog, temperature, relay and safety I/O modules on-site
• Complete native security functionality meets modern factory IT/OT convergence compliance requirements
