A-B 2711R-T10T PanelView 800 HMI Terminal

Product Description

The Allen-Bradley 2711R-T10T PanelView 800 HMI Terminal is a 10.4-inch touchscreen Human Machine Interface (HMI) manufactured by Rockwell Automation (Allen-Bradley). It is designed for machine operator interaction, allowing users to monitor equipment status, adjust parameters, display alarms, and control industrial processes.

The terminal features a color TFT touchscreen display, Ethernet and serial communication interfaces, and is commonly used with Allen-Bradley PLC systems such as Micro800, MicroLogix, CompactLogix, and other industrial controllers.

Detailed Specifications

Advantages & Features

• Large 10.4-inch color touchscreen for clear operator visualization
• Supports real-time machine monitoring and control
• Ethernet and serial communication options
• Compatible with multiple Allen-Bradley PLC platforms
• Supports alarm display, data monitoring, and parameter adjustment
• Compact panel-mounted design
• Supports application transfer via USB and microSD card
• Suitable for OEM machines and standalone automation systems

Applications

• Factory Automation Systems
• Packaging Machinery
• CNC Equipment
• Assembly Lines
• Material Handling Systems
• Machine Control Panels
• PLC Operator Stations
• Process Monitoring Systems

Precautions

• Verify PLC communication protocol and firmware compatibility before installation.
• Backup the existing HMI application before replacement.
• Confirm correct 24 VDC power wiring.
• Avoid damage to the touchscreen surface during installation.
• Ensure the panel cutout size matches the installation requirements.
• Configure communication parameters before commissioning.
