A-B 1783-MMX8SA Stratix Expansion Module

Product Description

The Allen-Bradley 1783-MMX8SA Stratix 5800 Expansion Module is a network expansion module manufactured by Rockwell Automation (Allen-Bradley). It is designed to expand the port capacity of Stratix 5800 managed industrial Ethernet switches, providing additional high-speed fiber connectivity for industrial communication networks.

The module adds 8 SFP 100/1000 Mbps slots, allowing users to connect fiber optic transceivers for long-distance Ethernet communication, network redundancy, and high-performance industrial applications.

Detailed Specifications

Advantages & Features

• Expands Stratix 5800 switch network capacity
• Provides 8 additional SFP fiber ports
• Supports 100 Mbps and Gigabit Ethernet communication
• Enables fiber optic connections for long-distance networking
• Suitable for industrial Ethernet backbone networks
• Supports advanced Stratix managed switch functions
• Helps improve network flexibility and scalability
• Designed for harsh industrial automation environments

Applications

• Industrial Ethernet Networks
• Factory Automation Systems
• PLC Communication Networks
• Control System Backbones
• Remote I/O Networks
• SCADA Communication Systems
• Power and Process Automation
• Large Manufacturing Facilities

Precautions

• This module is not a standalone Ethernet switch; it requires a compatible Stratix 5800 switch base unit.
• Confirm SFP transceiver compatibility before installation.
• Verify firmware compatibility between the expansion module and switch.
• Use proper fiber optic cabling and connectors.
• Power down equipment before installing or removing the module.
• Configure network settings after hardware installation.
