A-B 2711P-RDB15C PanelView Plus Display Module

Allen-Bradley 2711P-RDB15C PanelView Plus Display Module

Product Description

The Allen-Bradley 2711P-RDB15C is a PanelView Plus 1500 Display Module designed for PanelView Plus operator terminals. It features a 15-inch color TFT LCD with keypad and touchscreen input, providing a reliable HMI interface for industrial automation and machine control applications. This module is intended as a replacement display for compatible PanelView Plus 1500 terminals. It has been discontinued by Rockwell Automation but remains widely used for maintenance and repair of existing systems.

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 2711P-RDB15C
• Product Type: PanelView Plus Display Module
• Series: PanelView Plus 1500
• Display Size: 15 inches
• Display Type: Color Active Matrix TFT LCD
• Resolution: 1024 × 768 pixels
• Display Area: 304 × 228 mm
• Brightness: 300 cd/m²
• Operator Input: Keypad and Analog Resistive Touchscreen
• Input Voltage: 85–264 VAC
• Power Consumption: 70 W max (39 W typical)
• Backlight: CCFL (50,000-hour minimum life)
• External Storage: CompactFlash up to 512 MB
• Mounting: PanelView Plus 1500 modular terminal
• Country of Origin: United States
• Lifecycle Status: Discontinued (September 30, 2022)

Advantages & Features

• Large 15-inch industrial color display
• Combines keypad and touchscreen operation
• High-resolution 1024 × 768 display
• Designed for PanelView Plus 1500 modular HMIs
• Easy replacement of damaged display assemblies
• Rugged design for industrial environments
• Supports CompactFlash memory expansion
• Compatible with existing PanelView Plus logic modules

Applications

• Industrial HMI systems
• PLC operator interfaces
• Machine automation
• Production line monitoring
• Process control systems
• Factory automation
• Packaging equipment

Notes / Precautions

• Display module only; logic module is sold separately.
• Compatible with PanelView Plus 1500 terminals only.
• Verify hardware series and firmware compatibility before replacement.
• Disconnect power before installing or removing the display module.
• Rockwell Automation discontinued this model on September 30, 2022
