A-B 1756-A10 ControlLogix Chassis

Allen-Bradley 1756-A10 ControlLogix Chassis

Product Description

The Allen-Bradley 1756-A10 is a 10-slot ControlLogix chassis designed for the ControlLogix 1756 automation platform. It provides the physical mounting structure and high-speed backplane communication for ControlLogix controllers, I/O modules, and communication modules. The chassis distributes power and enables data exchange between installed modules in industrial control systems.

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1756-A10
• Product Type: ControlLogix Chassis
• Series: ControlLogix 1756
• Slot Capacity: 10 slots
• Backplane: High-speed ControlBus backplane
• Compatible Modules:
  • ControlLogix Controllers
  • Digital I/O Modules
  • Analog I/O Modules
  • Communication Modules
• Power Supply: Requires separate 1756 power supply module
• Cooling Method: Natural convection cooling
• Mounting: Panel mounting
• Operating Temperature: 0…60 °C
• Power Dissipation: Approx. 5 W
• Protection Rating: Open-style industrial chassis
• Communication Function: Provides backplane communication and module power distribution

Advantages & Features

• Supports up to 10 ControlLogix modules in a single chassis
• Provides reliable high-speed communication between modules
• Modular design allows flexible system expansion
• Compatible with a wide range of ControlLogix automation components
• Simplifies installation and maintenance of PLC control systems
• Suitable for large-scale industrial automation applications

Applications

• Factory automation systems
• Process control systems
• Machine automation
• Production line control
• Remote I/O systems
• Industrial PLC cabinets
• Manufacturing equipment

Notes / Precautions

• Requires compatible 1756 power supply module
• Verify chassis slot requirements before installation
• Ensure all installed modules are compatible with the ControlLogix platform
• Install horizontally according to Rockwell Automation guidelines
• Check backplane power requirements when adding modules
