A-B 1783-HMS8T4CGN Stratix Industrial Ethernet Switch

Product Description

The Allen-Bradley 1783-HMS8T4CGN Stratix 5400 Industrial Ethernet Switch is a 12-port managed industrial Ethernet switch manufactured by Rockwell Automation (Allen-Bradley). It is designed for industrial automation networks, providing reliable Ethernet communication between PLCs, HMIs, remote I/O, drives, and other industrial devices.

This model features 8 × 10/100 Mbps copper RJ45 ports and 4 × combo 10/100/1000 Mbps ports (RJ45/SFP). It supports Layer 2 managed switching, Device Level Ring (DLR), CIP Sync, and Network Address Translation (NAT) functions for advanced industrial network applications.

Detailed Specifications

Advantages & Features

• High-performance Stratix 5400 managed Ethernet switch
• Supports industrial EtherNet/IP communication networks
• 12-port high-density network connectivity
• Integrated DLR (Device Level Ring) support for network redundancy
• Supports CIP Sync IEEE 1588 for time synchronization
• NAT function simplifies machine network integration
• Layer 2 switching with advanced management functions
• DIN rail installation for industrial control cabinets
• Wide operating temperature range for harsh environments

Applications

• Factory Automation Networks
• PLC Communication Systems
• EtherNet/IP Control Networks
• Remote I/O Systems
• HMI and SCADA Networks
• Robotics and Motion Control Systems
• Automotive Manufacturing Lines
• Process Automation Equipment
• Industrial Control Cabinets

Precautions

• Confirm network configuration and firmware compatibility before replacement.
• Use suitable industrial Ethernet cables and connectors.
• Ensure correct DC power supply voltage (12–54 VDC).
• Configure VLAN, NAT, DLR, and other managed functions according to system requirements.
• Backup switch configuration before replacement.
• Install in a suitable industrial environment with proper grounding.
