A-B 1756-RM2 ControlLogix Redundancy Module

Product Description

The Allen-Bradley 1756-RM2 ControlLogix Redundancy Module is an Enhanced Redundancy Module manufactured by Rockwell Automation (Allen-Bradley). It is designed to create high-availability redundant ControlLogix PLC systems by synchronizing two separate ControlLogix chassis, allowing automatic controller switchover when a primary controller fault occurs.

The 1756-RM2 module works in pairs, with one module installed in each redundant chassis. It uses fiber optic communication for chassis synchronization and supports high-speed redundancy communication up to 1000 Mbps.

Detailed Specifications

Advantages & Features

• Provides high availability PLC redundancy
• Supports automatic controller switchover
• Synchronizes primary and secondary ControlLogix chassis
• High-speed fiber optic redundancy link
• Supports up to 1000 Mbps synchronization speed
• Reduces downtime in critical industrial processes
• Compatible with ControlLogix redundant controller architectures
• Supports redundant EtherNet/IP and ControlNet system configurations
• Suitable for continuous operation applications

Applications

• Process Automation Systems
• Oil & Gas Control Systems
• Power Generation Plants
• Chemical Processing Equipment
• Water Treatment Systems
• Large Manufacturing Lines
• Critical PLC Control Applications
• High Availability SCADA Systems

Precautions

• Requires two 1756-RM2 modules for a complete redundancy system.
• Ensure both redundant chassis have compatible hardware and firmware.
• Use approved fiber optic redundancy cables.
• Verify controller and communication module compatibility before installation.
• Backup existing PLC configuration before replacement.
• Perform redundancy synchronization testing after installation.
