Allen-Bradley 1762-OB16 MicroLogix Digital Output Module

Product Overview

The Allen-Bradley 1762-OB16 MicroLogix Digital Output Module is a 16-point 24V DC source output expansion module designed for the MicroLogix 1200 PLC system. It provides additional digital output channels for controlling actuators, solenoid valves, relays, contactors, and other field devices in industrial automation applications. The module features LED status indicators, isolated output groups, and a compact design for control cabinet installation.

Specifications

Advantages & Features

• Provides 16-channel digital output expansion for MicroLogix systems
• Supports 24V DC sourcing output devices
• LED indicators allow quick troubleshooting
• Compact design saves control cabinet space
• Reliable switching performance for industrial equipment
• Supports connection of multiple field devices
• Easy installation with screw terminal wiring
• Suitable for continuous automation operation

Applications

• Industrial Automation Systems
• PLC Control Panels
• Machine Control Equipment
• Packaging Machinery
• Conveyor Systems
• Solenoid Valve Control
• Motor Starter Control
• Factory Production Lines

Precautions

• Verify compatibility with MicroLogix PLC models before installation.
• Confirm output type and wiring method.
• Do not exceed rated output current.
• Check load requirements before connecting devices.
• Ensure correct DC polarity and grounding.
• Disconnect power before installation or maintenance.
