- - Allen‑Bradley 1489-A1C200 Miniature Circuit Breaker

    Product Overview

    Single-pole miniature circuit breaker from Bulletin 1489-A series, C trip curve with 20 A rated current. It provides overload and short-circuit protection for medium-to-high power branch circuits inside industrial control cabinets, ideal for protecting control transformers, multiple solenoid manifolds, small auxiliary motors and various inductive loads with large startup inrush.

    Core Specifications

    Poles: 1-pole

    Rated nominal current: 20 A

    Trip characteristic: C curve, optimized for inductive loads with high inrush current at startup

    Rated operational voltage: 240 VAC / 48 VDC

    Short-circuit breaking capacity: 10 kA @ 240 VAC

    Terminal type: Screw terminals, compatible with 24–12 AWG copper conductors

    Mounting: Standard 35 mm DIN rail mounting

    Operating ambient temperature: -20 ℃ ~ +60 ℃

    Protection mechanism: Dual thermal-magnetic protection; delayed thermal trip for overloads, instantaneous electromagnetic trip for short circuits

    Status indicator: Mechanical visual flag to clearly show ON, OFF or tripped state

    Certifications: UL, cUL, CE certified; IP20 rating for indoor cabinet installation only

    Main Functions

    Overload protection: Automatically disconnect power under sustained overcurrent to avoid cable overheating and insulation degradation

    Short-circuit protection: Instantly cut off the circuit upon short-circuit faults to prevent equipment damage and fire risks

    Manual isolation function: Acts as a branch disconnect switch to fully cut power for safe maintenance and wiring modification

    Safeguard medium-power loads such as heavy-duty control transformers, multi-valve solenoid groups and auxiliary pump/fan motors

    Key Advantages

    Slim compact body reduces cabinet space occupation. C curve characteristic avoids nuisance tripping triggered by high inrush current from coils and transformers during startup. Visible mechanical trip indicator speeds up on-site fault diagnosis. Plug-on DIN rail design supports fast replacement without reworking wiring. Integrated dual thermal-magnetic protection delivers full-range safety protection for branch circuits.

    Typical Applications

    Heavy-duty control transformer branch protection, multi-solenoid valve bank power circuits, auxiliary pump and fan load protection, secondary distribution loops in large automation panels, medium-power auxiliary control circuits for packaging, metallurgy and material handling equipment
