- - Allen‑Bradley 1489-A1C100 Miniature Circuit Breaker

    Product Overview

    Single-pole miniature circuit breaker from Bulletin 1489-A series, C trip curve with 10 A rated current. It delivers overload and short-circuit protection for medium-power branch circuits inside industrial control cabinets, widely used to protect control transformers, multiple solenoid valves, small auxiliary motors and inductive control loads.

    Core Specifications

    Poles: 1-pole

    Rated current: 10 A

    Trip characteristic: C curve, suitable for inductive loads with large startup inrush current

    Rated operational voltage: 240 VAC / 48 VDC

    Short-circuit breaking capacity: 10 kA @ 240 VAC

    Terminals: Screw terminals, wire range 24–12 AWG copper wires

    Mounting: Standard 35 mm DIN rail

    Operating temperature: -20 ℃ ~ +60 ℃

    Protection type: Thermal delayed overload trip + electromagnetic instantaneous short-circuit trip

    Status indicator: Mechanical flag to display ON / OFF / tripped status

    Certifications: UL, cUL, CE certified; IP20, only for indoor cabinet installation

    Main Functions

    Thermal overload protection: Automatically disconnect power under continuous overcurrent to prevent cable overheating and insulation aging

    Instant short-circuit protection: Rapidly cut off circuit during short-circuit faults to avoid equipment burnout and fire hazards

    Manual isolation function: Serve as a disconnect switch to cut branch power for safe maintenance and wiring adjustment

    Protect medium-power loads including control transformers, multi-valve solenoid groups and auxiliary cooling fans

    Key Advantages

    Slim compact housing saves cabinet installation space. C curve design prevents nuisance tripping caused by high inrush current of coils and transformers during startup. Visible mechanical trip indicator accelerates on-site fault troubleshooting. Plug-in DIN rail structure enables quick replacement without rewiring. Dual thermal-magnetic protection provides comprehensive safety protection for branch circuits.

    Typical Applications

    Control transformer power branch protection, multi-solenoid valve control loops, auxiliary fan and small pump load protection, secondary distribution circuits inside automation panels, medium-power auxiliary control circuits for packaging and conveying equipment
