TELEMECANIQUE XML-A500D2S11 Ultrasonic Sensor Product Information

Model: XML-A500D2S11
Brand: TELEMECANIQUE SENSORS
Product Type: Ultrasonic Sensor
Series: XML / XX Sensor Family
Application: Non-contact object detection and distance measurement in industrial automation systems

Note: The model XML-A500D2S11 is identified in Telemecanique documentation as part of the XMLA pressure sensor series, not an ultrasonic sensor. It is an electromechanical pressure switch, used for hydraulic pressure monitoring applications.

Technical Specifications

• Product Type: Electromechanical Pressure Sensor / Pressure Switch
• Series: Telemecanique Sensors XM
• Model: XMLA500D2S11
• Pressure Range: 30…500 bar
• Controlled Medium: Hydraulic oil (0…160 °C)
• Pressure Connection: G 1/4 female thread (ISO 228)
• Switch Type: 1 threshold detection
• Contact Type: 1 C/O (SPDT)
• Electrical Connection: Screw terminal
• Cable Entry: Pg13 cable gland (9…13 mm)
• Adjustable Switching Point:
  • Rising pressure: 30…500 bar
  • Falling pressure: 10…455 bar
• Maximum Accidental Pressure: 1125 bar
• Destruction Pressure: 2250 bar
• Actuator Type: Piston
• Contact Material: Silver contacts
• Protection Rating: IP66
• Operating Temperature: -25…70 °C
• Standards: IEC 60947-5-1, UL 508, CSA C22.2 No.14

Advantages & Features

• High Pressure Monitoring Capability
  Designed for hydraulic systems requiring reliable pressure detection up to 500 bar.
• Reliable Mechanical Switching
  Uses snap-action contacts to provide stable and fast switching performance.
• Durable Industrial Design
  Robust metal enclosure and IP66 protection provide excellent resistance to industrial environments.
• Easy Adjustment
  External setting design allows convenient pressure threshold adjustment.
• Wide Application Compatibility
  Suitable for hydraulic control circuits, industrial machines, and automation equipment.
• Long Service Life
  Designed for continuous operation in demanding industrial applications.

Applications

• Hydraulic systems
• Industrial machinery
• Injection molding machines
• Hydraulic presses
• Machine tools
• Automation equipment
• Pump and compressor systems
• Process control systems
• Factory production lines

Precautions

• Confirm the pressure range and medium compatibility before installation.
• Do not exceed the maximum pressure rating.
• Ensure correct wiring of C/O contacts.
• Use proper sealing methods for G1/4 pressure connection.
• Avoid strong vibration, impact, and extreme environmental conditions.
• Disconnect power before maintenance or replacement.
• Installation should be performed by qualified technicians.
