SCHNEIDER SH31002P02F2000 Servo Motor Product Information

Model: SH31002P02F2000
Brand: SCHNEIDER ELECTRIC
Product Type: AC Servo Motor
Series: Lexium SH3
System Compatibility: PacDrive 3 / Lexium Motion Control System
Application: High-performance motion control and industrial automation systems

Technical Specifications

• Product Type: Servo Motor
• Series: Lexium SH3
• Compatible System: PacDrive 3
• Motor Frame Size: SH3 100 mm
• Power Supply: 115…480 V AC
• Phase: Three-phase
• Continuous Stall Torque: 5.8 N·m
• Peak Stall Torque: 18.3 N·m
• Continuous Power: 1900 W
• Maximum Speed: 6000 rpm
• Rated Speed:
  • 1000 rpm at 115 V
  • 2000 rpm at 230 V
  • 4000 rpm at 400 V
  • 4800 rpm at 480 V
• Maximum Current: 17.1 A rms
• Continuous Stall Current: 4.8 A
• Encoder Type: Absolute multiturn SinCos Hiperface encoder
• Encoder Resolution: 128 periods
• Brake: Integrated holding brake
• Holding Torque: 9 N·m
• Shaft Type: Smooth shaft
• Shaft Diameter: 19 mm
• Shaft Length: 40 mm
• Protection Rating: IP54 / IP65
• Connection: 90° angled connector

Advantages & Features

• High Dynamic Performance
  Provides high torque density and fast response for precise motion control applications.
• High Overload Capability
  Supports high peak torque operation, suitable for applications requiring frequent acceleration and deceleration.
• High Precision Feedback
  Equipped with an absolute multiturn SinCos Hiperface encoder for accurate position and speed control.
• Integrated Holding Brake
  Improves safety and positioning stability during machine stops or power-off conditions.
• Wide Voltage Compatibility
  Supports 115…480 V AC power systems for flexible global installation.
• Compact Industrial Design
  100 mm flange size with optimized structure for space-saving machine integration.
• Reliable Industrial Protection
  IP54/IP65 protection design provides durability in demanding industrial environments.

Applications

• Industrial automation systems
• Packaging machinery
• Robotics and motion control equipment
• CNC machines
• Printing and labeling machines
• Semiconductor manufacturing equipment
• Material handling systems
• Production line automation
• Precision positioning systems

Precautions

• Confirm compatibility with Schneider PacDrive 3 / Lexium drive systems before installation.
• Ensure the power supply voltage matches the motor specifications.
• Correctly connect motor power cable and encoder cable.
• Configure motor parameters before commissioning.
• Avoid operation in environments with excessive moisture, dust, vibration, or corrosive gases.
• Do not manually rotate or impact the motor shaft during installation.
• Ensure proper grounding to prevent electrical interference.
• Maintenance should be performed by qualified technicians.
