            • TELEMECANIQUE XB4BW33M5 Harmony XB4 Illuminated Push Button

              The TELEMECANIQUE XB4BW33M5 is a Schneider Electric Harmony XB4 metal illuminated push button with a green flush actuator, spring-return operation, and integrated universal LED. It is designed for 22 mm control-panel mounting and uses 230–240 VAC LED supply.

              Key Technical Specifications

              Parameter	Specification
              Brand	Telemecanique / Schneider Electric
              Model	XB4BW33M5
              Product Family	Harmony XB4
              Product Type	Illuminated Push Button
              Actuator Color	Green
              Actuator Style	Flush
              Operation	Spring Return / Momentary
              Mounting Diameter	22 mm (22.5 mm cutout)
              Bezel	Chrome-plated metal
              Fixing Collar	Zamak
              Contacts	1 NO + 1 NC
              Contact Operation	Slow-break
              LED	Integral Universal LED
              LED Supply	230–240 VAC, 50/60 Hz
              Rated Insulation Voltage	600 VAC
              Impulse Withstand	6 kV
              Thermal Current	10 A
              Terminals	Screw-clamp
              Protection	IP66 / IP67 / IP69 / IP69K
              Mechanical Durability	Up to 10 million cycles
              Weight	Approx. 0.097 kg

              Schneider's catalog confirms the XB4BW33M5 configuration as green, 1NO+1NC, 230–240 VAC, with an integral LED and spring-return mechanism.

              Advantages & Features

              • Rugged metal Harmony XB4 construction
              • Bright integrated LED indication
              • Green flush actuator for clear status indication
              • 1NO + 1NC contact configuration
              • Spring-return momentary operation
              • Standard 22 mm panel mounting
              • High environmental protection for industrial applications
              • Long mechanical service life
              • Screw-clamp terminals for secure wiring
              • Suitable for demanding industrial control panels

              Typical Applications

              • Industrial control panels
              • Machine control systems
              • Factory automation
              • Motor control panels
              • Production machinery
              • Process control equipment
              • Start/stop and status indication circuits
              • Industrial operator interfaces

              Important Precautions

              • Confirm the LED supply is 230–240 VAC before connection.
              • Verify the NO/NC contact wiring and electrical ratings.
              • Use suitable short-circuit protection; Schneider specifies 10 A gG cartridge fuse protection.
              • Ensure the panel cutout is approximately 22.5 mm.
              • Disconnect power before installation or servicing.
              • Do not confuse this model with the similar 24 VAC/DC or 110–120 VAC versions, which have different suffixes.
