          • TELEMECANIQUE XACA481 Harmony XAC Pendant Control Station

            Note: The official Schneider model is XACA481 (often written as XAC-A481). It is a complete Harmony XAC pendant control station with four push buttons, designed for single-speed hoist/motor control.

            Key Technical Specifications

            Parameter	Specification
            Brand	Telemecanique / Schneider Electric
            Model	XACA481
            Product Family	Harmony XAC
            Product Type	Pendant Control Station
            Enclosure	Double-insulated polypropylene
            Color	Yellow
            Push Buttons	4
            Contact Arrangement	4 × NO + 4 × NC
            Control	Raise / Lower / Left / Right
            Mechanical Interlocking	Yes, between opposing button pairs
            Application	Single-speed hoist motor control
            Protection	IP65
            Impact Protection	IK08
            Rated Insulation Voltage	600 VAC
            Impulse Withstand	6 kV
            Thermal Current	10 A
            AC-15 Rating	3 A at 240 VAC / 1.2 A at 600 VAC
            DC-13 Rating	0.27 A at 250 VDC / 0.1 A at 600 VDC
            Operating Temperature	-25 to +70°C
            Cable Entry	Stepped rubber sleeve, 8–26 mm
            Terminals	Screw-clamp terminals
            Mechanical Life	1,000,000 cycles
            Net Weight	Approx. 0.675 kg
            Standards	EN/IEC 60204-32, IEC 60947-5-1, UL 508

            The four buttons are configured for raise, lower, left and right functions, with mechanical interlocking to help prevent opposing commands from being activated simultaneously.

            Advantages & Features

            • Rugged IP65 industrial enclosure
            • Double-insulated polypropylene housing
            • Four integrated control push buttons
            • Mechanical interlocking between opposing functions
            • Highly visible yellow housing
            • Suitable for overhead and material-handling equipment
            • Long mechanical life up to 1 million cycles
            • Wide operating temperature range
            • Screw-clamp terminals for reliable wiring
            • Compact pendant design for convenient operator control

            Typical Applications

            • Overhead cranes
            • Hoists
            • Bridge cranes
            • Gantry cranes
            • Material-handling equipment
            • Lifting machinery
            • Industrial production lines
            • Single-speed reversing motor control

            Schneider's XAC documentation specifically lists applications including overhead cranes, tower cranes, fixed hoists and beam hoists.

            Important Precautions

            • Verify the contact configuration and wiring before installation.
            • Do not exceed the specified contact voltage/current ratings.
            • Use appropriate short-circuit protection; the datasheet specifies 10 A gG fuse protection.
            • Confirm the cable diameter is compatible with the cable entry.
            • Ensure proper grounding and control-circuit wiring.
            • The XACA481 is a control station, not a motor power controller; contactors or other suitable switching devices are required for motor power switching.
