TELEMECANIQUE LC1D80F7 TeSys D Contactor
Item NO.:
LC1D80F7Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The Telemecanique LC1D80F7 is a three-pole TeSys D contactor designed for industrial motor control and switching applications. It features an 80 A AC-3 rating and a 110 V AC control coil operating at 50/60 Hz.
|
Parameter |
Specification |
|---|---|
|
Brand |
Telemecanique / Schneider Electric |
|
Model |
LC1D80F7 |
|
Product Series |
TeSys D |
|
Product Type |
AC Contactor |
|
Number of Poles |
3P |
|
Main Contacts |
3 Normally Open (3 NO) |
|
Rated Current |
80 A (AC-3, up to 440 V AC) |
|
AC-1 Current Rating |
125 A |
|
Rated Operational Voltage |
Up to 690 V AC |
|
Motor Power |
37 kW at 380–400 V AC |
|
Coil Voltage |
110 V AC |
|
Coil Frequency |
50/60 Hz |
|
Auxiliary Contacts |
1 NO + 1 NC |
|
Dimensions |
Approx. 85 × 127 × 130 mm |
|
Mounting |
DIN rail or screw mounting |
Three-pole design for three-phase motor control.
80 A AC-3 rated operational current.
110 V AC control coil.
Built-in 1 NO + 1 NC auxiliary contacts.
Designed for industrial motor starters and control panels.
Compatible with selected TeSys D accessories.
Industrial motor control
Pumps and compressors
HVAC systems
Factory automation
Industrial machinery and electrical control panels
Verify the control circuit supplies 110 V AC at 50/60 Hz.
Confirm motor current and load category before installation.
Use appropriate overload and short-circuit protection.
Installation should be performed by qualified electrical personnel.
