SCHNEIDER BMXCPS3500 Modicon X80 Power Supply Module
Item NO.:
BMXCPS3500Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The Schneider Electric BMXCPS3500 is an AC power supply module for the Modicon X80 automation platform. It supplies the DC power required by compatible PLC processors, I/O modules, and sensors in industrial automation systems.
|
Parameter |
Specification |
|---|---|
|
Brand |
Schneider Electric |
|
Model |
BMXCPS3500 |
|
Product Series |
Modicon X80 |
|
Product Type |
PLC Power Supply Module |
|
Input Voltage |
100–240 V AC |
|
Input Voltage Limits |
85–264 V AC |
|
Frequency |
50/60 Hz |
|
Total Useful Secondary Power |
Up to 36 W |
|
3.3 V DC Logic Output |
15 W, up to 4.5 A |
|
24 V DC I/O and Processor Output |
31.2 W, up to 1.3 A |
|
24 V DC Sensor Output |
21.6 W, up to 0.9 A |
|
Protection |
Overload, overvoltage, short circuit |
|
Status Indicators |
Rack voltage OK and sensor voltage |
|
Reset Function |
Cold restart |
|
Protection Rating |
IP20 |
|
Weight |
Approx. 0.36 kg |
|
Backplane Compatibility |
Not compatible with BMEXBP..02 |
|
Mounting |
Modicon-compatible PLC rack |
AC input compatible with 100–240 V electrical supplies.
Provides 3.3 V DC and 24 V DC power outputs.
Built-in overload, overvoltage, and short-circuit protection.
LED indicators for monitoring power status.
Reset button for cold restart.
Designed for modular industrial PLC installations.
Modicon X80 PLC systems
Factory automation
Industrial process control
Distributed I/O installations
Machine control cabinets
Verify the input voltage and power requirements before installation.
Confirm compatibility with the installed rack and backplane.
Check the sensor supply and I/O power requirements.
Disconnect power before replacing or wiring the module.
Installation should be performed by qualified personnel.
