TELEMECANIQUE LC1-D80F7 Contactor
Item NO.:
LC1-D80F7Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
|
Parameter |
Specification |
|---|---|
|
Brand |
TELEMECANIQUE / Schneider Electric |
|
Model |
LC1-D80F7 / LC1D80F7 |
|
Product Type |
AC Power Contactor |
|
Series |
TeSys D |
|
Number of Poles |
3 |
|
Main Contacts |
3 NO |
|
Rated Operational Current |
80 A (AC-3, up to 440 V) |
|
Conventional Thermal Current |
125 A |
|
Coil Voltage |
110 V AC |
|
Coil Frequency |
50/60 Hz |
|
Rated Operational Voltage |
Up to 690 V AC |
|
Rated Insulation Voltage |
1000 V |
|
Auxiliary Contacts |
1 NO + 1 NC |
|
Motor Power |
Up to 37 kW at 380–400 V, subject to applicable ratings |
|
Mounting |
DIN rail or screw mounting |
|
Terminal Type |
Screw-clamp |
|
Dimensions (W × H × D) |
85 × 127 × 130 mm |
|
Weight |
Approx. 1.59 kg |
|
Front Protection |
IP20 |
Specifications based on Schneider Electric documentation. Motor power and current ratings depend on operating voltage and utilization category.
High Current Capacity: Supports demanding industrial motor control applications.
Reliable Switching: Designed for frequent switching of motors and electrical loads.
Long Service Life: High mechanical and electrical durability.
Auxiliary Contacts: Supports control logic, status feedback, and interlocking.
Flexible Installation: DIN rail or screw mounting for convenient panel integration.
Wide Applications: Suitable for industrial control systems and motor starters.
Industrial machinery and production lines
Pumps, compressors, and ventilation systems
Conveyor belts and material handling equipment
HVAC and water treatment systems
Motor control centers and electrical cabinets
Factory automation and power distribution systems
Verify that the control coil supply is 110 V AC, 50/60 Hz.
Check motor current, operating voltage, and AC-3 ratings before installation.
Use suitable circuit breakers or fuses for short-circuit protection.
Ensure all wiring and terminals are properly secured.
Disconnect the power supply before installation or maintenance.
Install in a suitable enclosure and follow applicable electrical safety standards.
