TELEMECANIQUE GV2-P20 Motor Protection Circuit Breaker
Item NO.:
GV2-P20Payment:
T/TPrice:
$650Product Origin:
JapanColor:
NEWProduct weight:
0.21KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
|
Parameter |
Specification |
|---|---|
|
Brand |
TELEMECANIQUE / Schneider Electric |
|
Model |
GV2-P20 / GV2P20 |
|
Product Type |
Motor Protection Circuit Breaker |
|
Series |
TeSys GV2 / TeSys Deca |
|
Poles |
3-pole (3P) |
|
Rated Operational Voltage |
Up to 690 V AC |
|
Frequency |
50/60 Hz |
|
Adjustable Current Range |
13–18 A |
|
Trip Technology |
Thermal-magnetic |
|
Magnetic Trip Current |
223 A (per datasheet) |
|
Motor Power |
7.5 kW at 400/415 V AC |
|
Short-Circuit Breaking Capacity |
50 kA at 400/415 V AC |
|
Operating Handle |
Rotary |
|
Terminals |
Screw-clamp |
|
Mounting |
35 mm DIN rail or screw mounting |
|
Dimensions (W × H × D) |
Approx. 45 × 89 × 97 mm |
|
Rated Insulation Voltage |
690 V AC |
|
Impulse Withstand Voltage |
6 kV |
Specifications based on Schneider Electric documentation. Breaking capacity varies with operating voltage; verify the applicable rating before installation.
Reliable Motor Protection: Provides thermal overload and instantaneous short-circuit protection.
Adjustable Current Setting: 13–18 A adjustment range for matching motor rated current.
Compact Design: Saves space in control cabinets and motor control panels.
Easy Operation: Rotary handle enables convenient manual switching and isolation.
Flexible Installation: Supports DIN rail and screw mounting.
Industrial Durability: Designed for dependable operation in motor control applications.
Industrial machinery and production lines
Pumps and water treatment systems
Fans, blowers, and ventilation equipment
Conveyor systems and material handling
Compressors and general-purpose motor drives
Electrical control panels and motor control centers
Set the thermal protection current according to the motor nameplate and applicable electrical standards.
Verify the rated voltage, motor current, and prospective short-circuit current before installation.
Ensure all terminals are securely tightened to the manufacturer's specified torque.
Disconnect and isolate the power supply before installation or maintenance.
Use a qualified electrician and follow local electrical safety regulations.
Confirm the unit's condition and compatibility before replacing an existing circuit breaker.
